Max7219 4 In 1 Red Led Display Dot Matrix Module For Arduino

US $120

  • Shanghai, China
  • May 31st
MAX7219 4 in 1 Red LED Display Dot Matrix Module for Arduino Description The MAX7219 are compact, serial input/output common-cathode display drivers that interface microprocessors (μPs) to 7-segment numeric LED displays of up to 8 digits, bar-graph displays, or 64 individual LEDs. Included on-chip are a BCD code-B decoder, multiplex scan circuitry, segment and digit drivers, and an 8x8 static RAM that stores each digit.Only one external resistor is required to set the segment current for all LEDs. The MAX7219 is compatible with SPI™, QSPI™, and Microwire™, and has slew-ratelimited segment drivers to reduce EMI.A convenient 3-wire serial interface connects to all common μPs. Individual digits may be addressed and updated without rewriting the entire display. The MAX7219 also allow the user to select code-B decoding or no-decode for each digit.The devices include a 150μA low-power shutdown mode, analog and digital brightness control, a scanlimitregister that allows the user to display from 1 to 8 digits, and a test mode that forces all LEDs on.   Features: A single module can drive a 8x8 dot matrix common cathode Module Working voltage: 5V Module size: 12.8 cm X12.8 cm X1.3 cm(L*W*H) With 64 fixing screw holes, Hole diameter 3mm Module with input and output interfaces, support for cascading multiple modules Wiring:for example 51 SCM VCC→5V GND→GND DIN→P2.2 CS  →P2.1 CLK→P2.0 Package Include: 1pcs MAX7219 4 in 1 Red LED Display Dot Matrix Module for Arduino Payment We accept Paypal as payment Delivery details Delivery to most of the countries will take 2-4 weeks, if there's no problem when pass through the customs. Please make sure your shipping address is correct.Any non-received items caused by invalid or wrong shipping address are not in our full refund or replacement policy. The extra fee occured when the product pass through the customs should be paid by buyer Terms of sales The default shipping is by China Post air mail/Hongkong air mail to worldwide. We provide you combine shipping by e-Packet Service to USA and only charge you 1.8USD for each order. Item will be shipped within 1-2 working days after your cleared payment.Note:order more than $50, we provide free tracking number, order less than $60, customer need to pay $2 if need tracking number. About us We are a company based in China developing and manufacturing electronic development device , including electronic components ,camera module, camera lens , LCD modules and other development board for Raspberry pi,Arduino and other opensource hardware Platform We can also provide customized design and manufacture services according to your requirements. Contact us If you have any questions, please feel free to leave us ebay message or email us directly! On May-18-16 at 10:53:28 PDT, seller added the following information:
