Magnetics Inc Oj-43615-tc, F-140a-j Toroid Ferrite Core (12 Pieces Lot)

US $140

  • Orange, California, United States
  • Jun 3rd
MAGNETICS INC OJ-43615-TC  FERRITE CORE, TOROID, J MATERIAL, Permeability 5000 You are buying a lot of (12 pieces).  Part Number: OJ-43615-TC / F-140A-J Manufactured by Magnetics Inc, Pennslyvania, USA Core Type: Toroids Toroid Core Size: OD = 36 mm (1.417 inch) x ID = 23 mm (0.906 inch) x HT=15 mm (0.59 inch)   Material Grade: J Permeability of 5000, Max Permeability 9500 Saturation Flux density 4300 gauss  at 10 oersted, 25 deg C Residual Flux Density 500 gauss, Volume resistivity 100 ohms-cm, Curie temp 140 deg C. Le = Effective Magnetic Path Length: 8.97 cm  Ae = Effective Cross Scetion Area: 0.946 cm2  Ve = Volume : 8.48 cm3 Al = Inductance Factor : 6736 nH  RoHS Compliant Application / Uses :  J material with permeability of 5000 is the most widely used ferrites core for common mode chokes. It is also used as EMI/RFI filters for amateur radio bands ( 3 Mhz to 30 Mhz) by wrapping the cables around the cores. Low Volume resistivity, and low core loss from 1 Khz to 1 Mhz range, it is also used as pulse transformers and low level wideband transformers. As Common mode chokes and filters, the effective range is filtering out noise from 500 Khz to 100 Mhz. But best attentuation is from 500 Khz to 20 Mhz.
