Magnetic Flexible Base Holder Stand + Dial Test Indicator Gauge Scale Precision

US $200

  • HK, Hong Kong
  • Nov 17th
Dial Test Indicator Gauge Scale Precision  + Magnetic Flexible Base Holder Stand Description    Dial Test Indicator Gauge Feature inch/metric dial test indicator with yellow face is designed to measure surface variations in narrow or recessed areas 0-0.8mm measuring range, 0.0005"/0.01mm graduations, 0-40-0 balanced inch readings, and 0.001mm balanced metric readings Auto-reversing contact point and adjustable bezel Three dovetail mounts for mounting indicator from the top,back,or front One-piece housing with satin chrome finish provides durability This dial test indicator is designed for taking measurements in machining,layout,and inspection work.The dial has microfine black graduations for 0-40-0 balanced inch readings and red graduations for 0.001mm balanced metric readings.A movement and an auto-reversing contact point provide smooth action.A knurled bezel rotates 360 degrees to zero the reading at any location.Three dovetail mounts on the top,back,and front of the indicator provide a range of mounting options.The one-piece housing and satin chrome finish provides durability. This dial test indicator includes one 3/8" and one 5/32" dovetail clamp and a molded case.Dial readings with three digits,0-40-0 for example,signify that the indicator has a balanced dial. Dial readings with two digits, 0-100 for example,indicate the dial has a continuous dial.Balanced dials are used for reading the difference from a specific surface reference point.Continuous dials are used for direct readings and usually have a larger measurement range than balanced dials. Specifications   Face 1-1/4" diameter yellow face Dial type and reading 0-40-0 balanced inch and 0-.25-0 balanced metric readings Range 0-0.8mm Graduations 0.0005"/0.01mm Contact point length 1/2" Dovetail clamps 3/8" and 5/32" Mounting type Dovetail Characteristic & Function   A magnetic stand that uses a switchable permanent magnet for convenient mounting onto  flat iron or steel surfaces. The arm can be hydraulically locked in any position using the knob  on the upright . Useful for holding dial indicators or dial test indicators during alignment operations.   Flexible Magnetic Base Holder Stand Features   Permanent magnet operation with ON/OFF control. V-grooved base for secure mounting on cylindrical surfaces. Ideal for holding lever indicators at any orientation on a machine tool for alignment operations. Flexible, strong, and precise rotary joints,can adjust any direction and location Powerful magnetic base, with on/off switch for magnet With high stability, it will be your ideal tool in the measurement of precision workpiece field. One magnetic base It can used for dial indicator and lever dial indicator, etc Designed with three joints Easy using for metalwork pieces There is On/Off switch on the base Specifications Base Size(L x W x H): Approx. 40 x 29 x 35mm Total Height: Approx. 19.4cm Clamping Hole Diameter: Approx. 8mm Material: Metal Package include: 1* yellow-face dial test indicator 1* 3/8" dovetail clamp 1* 5/32" dovetail clamp 1* Molded case 1 x Universal Magnetic Base Stand Payments We only accept Paypal payment. All payments should be received within 7 working days after auction has ended. Non-paying bidders will be reported to ebay. If you can not pay in time, plz contact us Payment Mothods Shipping Details Item will be shipped out within 48 hours upon receipt of your payment. We ship the item through Hong Kong Air mail. Please make sure your address in eBay is correct. If you want to change the address, please give us ebay message right away you make the payment.  Combing shipment is not allowed. If you wants to combine all the items together, you should still pay for all of the shipping, insurance and handing fees. Considering the cost of business and easy shipping, usually the item is packed in retail packaging.   Normally, the item will arrive in 15-20 days. But sometimes it takes a little bit longer, goes to 20-30 days or more. Warranty& Return Any question,don't hesitate to contact us. If for some reason you are not satisfied with your purchase please email us within 3 days of receiving for an exchange or a retun. If returning item(s) must be in original condition (unused in any way) and with all originalpackaging, manuals, and accessories. Buyer is Responsible for all Shipping Charges.   About us Our goal is to make sure you are a happy buyer and pleasant shopping with us.  We understand the concerns and frustrations you might have, and will do our endeavor to resolve the issues. Please give us the opportunity to resolve any problem.   On Nov-11-16 at 00:47:22 PST, seller added the following information:On Nov-16-16 at 19:39:09 PST, seller added the following information: inkFrog Analytics
