Kyoritsu 6011a Digital Multifunction Tester

US $1,210.00

  • Shanghai, China
  • Jan 29th
  Kyoritsu 6011A Digital Multifunction Tester New Kyoritsu 6011A Digital Multifunction Tester, 100% new factory packed and never been used. New Kyoritsu 6011A Digital Multifunction Tester, suitable for multifunction testing of appliances and installations   Features: Complies with IEC 61557 Designed to IP 54 Rating Live circuit and wiring connection check LED's Triple ranges insulation tests at 250, 500 and 1000V Triple range loop and PSC tests 15mA test current at 200?/2000? range(No RCD Trip) Phase angle selection on RCD ranges Polarity switch for continuity tests Auto-null facility for continuity tests Earth probe for loop impedance testing on extraneous metalwork Contact Voltage Reading Test of a large kind of RCD's: Standard, Selective, AC and A(DC sensitive breakers) Closer Look: Specifications: Brand: kyoritsu Gross Weight: 1250g SKU: STINF-MT-0029   Continuity Testing Measuring Ranges 20/200/2000? (Autoranging) Open Circuit Voltage >6V Short Circuit Current >200mA DC Accuracy ±(1.5%rdg+3dgt) Insulation Testing Measuring Ranges 20/200M? (Autoranging) Test Voltage 250V 500V 1000V DC Output Voltage on Open Circuit 250V+40%-0% 500V+30%-0% 1000V+20%-0% Rated Current > 1mA Accuracy ±(1.5%rdg+3dgt) Loop Impedance Testing Rated Voltage 230V AC +10%-15% [50Hz] Voltage Measuring Range 100~250V AC [50Hz] Impedance Ranges 20/200/2000? Nominal Test Current 25A (20? range) 15mA (200? range) 15mA (2000? range) Accuracy 20? range ±(3%rdg +4dgt) 200? range ±(3%rdg +8dgt) 2000? range ±(3%rdg +4dgt) PSC Testing Rated Voltage 230V AC +10%-15% [50Hz] PSC Ranges 200A (15mA Test Current) 2000A (25A Test Current) 20kA (25A Test Current) Accuracy PSC accuracy derived from measured loop impedance specification and measured voltage specification RCD Testing Rated Voltage 230V AC +10%-15% [50Hz] Trip Current Settings RCD x 1/2 : 10,30,100,300,500,1000mA RCD x 1 : 10,30,100,300,500,1000mA RCD x 5 : 10,30,100,300mA (on x 5 ranges max current 1A) Trip Current Duration RCD x 1/2 x 1: 2000ms  RCD fast: 50ms Accuracy Trip current +10%-0% of test current at 230V Trip time ±(1%rdg + 3dgt) General Safety Standard IEC 61010-1 CAT.III 300V Pollution Degree 2 IEC 61557 Withstand Voltage 3700V AC for 1 minute Power Source LR6 (1.5V) x 8 Dimensions 130(L) x 183(W) x 100(D)mm Package Includes:     1 x Kyoritsu 6011A Multifunction Tester Original Package Welcome to our eBay store! To make your purchase as simple and easy as possible, please refer to the store policies listed below. After winning an item in auction or completing a Buy It Now purchase, you have two check-out options: Check-Out Now! Click the Pay Now button at the top of this listing to immediately proceed with our checkout and payment process. Please note that the Pay Now button is ONLY available after winning an auction or completing a Buy It Now purchase. Check-Out Later If you do not choose to Check-Out now, you will be notified by eBay via e-mail that you are the winning bidder. There is no need to contact us to arrange payment. We will automatically send you an invoice within twenty-four hours of an auction closing with instructions regarding how to pay later. You may also continue purchasing additional items from our auctions or eBay store. You have seven days from the end of the first purchase to add additional items to your order. Make sure all of your auctions have ended prior to checking out. All of your purchases will be consolidated into one checkout! *Remember that your winning bid is a contract; you must pay for items purchased.  Please contact us if you expect to make payment more than seven days from the end of your winning auction. Payment We accept the following forms of payment. PayPal   Shipping Item will be shipped within 2 working days after full payment is received. You should receive the item within 10 to 15 business days after shipment.  Email us if you have not received your item within 3 weeks from payment. We only ship to the approved address given through PayPal - Please make sure your payment address in PayPal is correct. Any non-received items caused by invalid address registered on PayPal are not covered by warranty. A shipping notification email will be sent to buyer after the item is shipped. Customer Service We encourage our customers to communicate with us through eBay messages. If you have any questions or comments whatsoever regarding our products or listing, we are waiting to hear from you. Return Policy In the unlikely event that a return is request, all returns must include all original items undamaged, in re-saleable condition, all original packaging including manuals, warranty forms, etc. Software sales are not refundable. Shipping and handling fees are not refundable. Buyer is responsible for shipping costs incurred shipping products back.
