Jy-mcu 3208 Lattice Dot Matrix Clock Ht1632c Driver With Mcu

US $17.00

  • Our Warehouse in China Mainland, China
  • Mar 4th
JY-MCU 3208 Lattice Dot Matrix Clock HT1632C Driver With MCU Description: The module ASIC driver HT1632C lattice- without requiring an MCU scan- do not take MCU resources- 16 adjustable brightness- saving three IO lines / four-wire interface module is reserved for a ATMEGA8 microcontroller- AVR USB- mini USB Chip Block- buzzer- 18B20 temperature sensor- LED metering port- infrared receiver interfaces- RTC clock module (reserved)- three separate buttons- AD input supply voltage can be measured- easy to do secondary development. The module is pre-installed basic HT1632C peripheral circuits and ATMEGA8 +32768 crystal- other parts required to install itself.  the purchase of the module schematics- AVR sample program. As the color reasons- looks like a yellow dot is actually red. If you need CODE of this item- please contact our customer service- or send email to wangzhanxiemeijuan@banggood.cn Feature: Time display Time- date adjustment- with leap year compensation (2000 - ~ 2099) Date and temperature every 5 minutes to scroll through once (the version without 18B20- temperature invalid- buy their own installation) The time display on the move 16-level brightness adjustment Specification: Power: 3V ~ 5V Minimum operating current: <30mA (5V- lowest brightness- lowest brightness can be used indoors) Maximum Operating Current: <300mA (5V- maximum brightness- glare) Dimensions: 6.85 in x 1.50 in x 0.59 in (17.4 cm x 3.8 cm x 1.5 cm) Weight: 2.86 oz (81 g) Note: The electronic clock did not go when the power-down function- described on the instructions provided to achieve the source- only for learning to use open source- do not promise custom functions will continue to provide follow-up version of the source. Package included: 1 x Dot matrix clock
