Jdsu Wavetek Series Field Meter Dsam Xt 2300 Network Install Tool W/ Cords

US $1,599.99

Tulsa, Oklahoma, United States
Jun 9th

Open on mobile:
QR code

JDSU Acterna DSAMxt-2300 Digital Service Activation Meter Comes with everything you see pictured. Unit/ Case/ Power Supply/ Carrying Strap/ Car Lighter Power Cord Please Note This is An Annex B Model Which Does Not Have EuroDOCSIS Capability. EuroDOCSIS Capability Requires Annex A. If You Are Performing Testing In A European Market Please Be Aware That This Meters DOCSIS Function Will Not Work. This Unit Is Capable Of Docsis 3.0 6MHz Annex B Testing Only! Refurbished / Calibrated Everything included. Has folder for Home Certification in autotest, just needs software. You may be able to download. DSAM-2300 FEATURES * = Factory Installed OPT = Optional N/A = Not Applicable Analog and Digital Carrier Level Verification Analog video and audio power levels * Digital power level * Tilt (1 to 12 channels) * Mini-scan (1 to 12 channels) * Full-scan (1 to 999 channels) * Analog carrier-to-noise * Hum * SmartScan™ OPT Spectrum Analyzer with Auto Pre-Amp OPT Digital Carrier Quality (QAM Carriers) MER/EVM measurements * Pre- and post-FEC BER (64, 128, 256) * BER for Deep Interleave (128,4 or 128,5) * Constellation (64, 128, 256) OPT Digital Quality Index™ (DQI) * AGC Stress * Errored/severely errored seconds * QAM Ingress OPT Upstream Physical Verification Return Loopback (requires QAM Hardware Option) OPT Local upstream spectrum for ingress check * Return QAM Generator OPT Spectrum Analyzer w/Auto Pre-Amp OPT Field View of the PathTrak Return Spectrum (requires QAM Hardware Option) OPT DOCSIS Testing DOCSIS 2.0/1.1/1.0 testing 1 Downstream x 1 Upstream * DOCSIS 3.0 Bonded Carrier testing 8 Downstream x 4 Upstream OPT Downstream MER/EVM, Pre- and Post-FEC BER * Dynamic DOCSIS Range and Registration * Cable modem configuration file verification * Upstream channel selection * Upstream transmit level and headroom * Cable modem and CPE MAC cloning * CableLabs® issued certificates * DOCSIS Service Tests Packet Loss * Throughput - Upstream and Downstream (Up to DOCSIS 3.0 rates) * Ping * VoIPCheck - Voice over IP testing (MOS, Packet Loss, Jitter, Delay) OPT Basic Ethernet Testing Throughput - (DOCSIS 2.0 rates) OPT Packet Loss OPT Ping OPT View CM diagnostics page * Gigabit Ethernet Testing Throughput - (DOCSIS 3.0 rates) OPT Packet Loss OPT Ping OPT Gig-E testing - DOCSIS 3.0 Support up to 400 Mb/s down OPT RF Network Verification Forward Sweepless Sweep™ OPT Reverse Alignment N/A Forward (Downstream) Sweep N/A Reverse (Upstream) Sweep N/A Return Loopback (requires QAM Hardware Option) OPT HFC Network Verification Scheduled Autotest * Proof Test * Home Network Verification IP Tests via 10/100/1000 Ethernet jack OPT Ingress Resistance Test (IRT) * Fault Location using FDR feature in LST-1700 remote transmitter * Test Point Compensation * Autotest Home Certification OPT no Video Autotest * Cable Modem Autotest * Combination Autotest (Video and Cable Modem) * Proof of Performance (Scheduled autotest) * Web Browser OPT Miscellaneous RF or Ethernet synchronization with TPP * Secure Sync™ - RF Synchronization through firewalls * The Acterna DSAM is a high-speed data installer meter that increases the number of cable modem installs per day. Using exclusive digital signal processing and integrated DOCSIS chipset technology, the meter communicates with the network CMTS to verify suitable conditions for cable modem installation from the subscriber's location. The DSAM is also equipped with signal level meter capabilities, including spectrum scanning for ingress assessment and mini-scan analysis of up to twelve analog and/or digital channels. The meter's AutoTest capability makes installations easier and more reliabe than ever before. The new DSAM DOCSIS 3.0 models provide the best in class combination of full DOCSIS 3.0 testing combined with a powerful Signal Level Meter and QAM analyzer. Highlights 8 downstream x 4 upstream DOCSIS 3.0 testing Throughput testing of bonded services Up to 304 Mbps down, 120 Mbps up (6 MHz carriers) Gigabit Ethernet port standard Optional Gig E Throughput testing available Improved Digital Carrier testing Deep interleave video BER standard MER range up to 45 dB DQI measurement capability MoCA® compatible Cable Labs®-compliant certificates Legacy support for DOCSIS 1.0, 1.1, and 2.0 Includes all measurements and features of previous models Fully featured SLM (Signal Level Meter) with QAM analysis and integrated DOCSIS® cable modem Reduce repeat truck rolls Increase productivity and with comprehensive Home Certification test Consistent and accurate testing and reporting powered by the Tech Complete™ TPP software Powerful troubleshooting of service impairments with DQI, QAM Ingress, and VoIP Check Weatherproof, rugged & lightweight to meet the demands of field technicians Remote meter management with consistent and accurate test reporting powered by the Tech Complete™ TPP software Powerful microprocessor and color display for fast power up and dramatic display clarity, now shipping as DSAMXT 4 to 1000 MHz range with optional 42 MHz, 65MHz, or 85MHz diplexers to match the return path Applications Conduct full DOCSIS 3.0 performance testing Perform 8 downstream by 4 upstream bonded carrier testing Troubleshoot digital QAM carriers - troubleshoot and eliminate intermittent HDTV and HSD service impairments with JDSU’s unique DQI, QAM Ingress, and VoIP Check™ Find Return Path Ingress Verify service quality - Qualify the quality and availability of revenue generating Voice, Cable Modem, and Digital Video services at installation time Home Certification™ reports - Establish consistent installation and service procedures to reduce repeat truck rolls with DSAM’s Home Certification option Legacy testing of DOCSIS 1.X and 2.0 Non-invasive forward and reverse sweeping Test digital and analog video Ethernet Testing of customers service Troubleshoot upstream noise and service issues interactively with PathTrak™ using Field view and QAM demodulation on RPM-3000 Segment HSD and VoIP problems between HFC network and IP backbone with JDSU’s exclusive VoIP Check™ Key Features 8 downstream x 4 upstream DOCSIS 3.0 testing Digital carrier testing with up to 45 dB MER range Integrated Pre-Amplifier for -45dBmV ingress scans and return path troubleshooting Complete DOCSIS® testing of carriers including MER, BER, throughput, packetloss, jitter, and delay DQI Digital Quality Index to help find and eliminate intermittent problems Home Certification test simplifies fulfillment testing and reduces truck rolls QAM Ingress – finds noise and interferers inside the QAM carrier VoIP Check option – Provides MOS call quality ratings and segments HFC and IP issues 24 hour Proof of Performance testing including Hum, C/N, MER, BER and Power Levels Powerful spectrum analysis Upstream 16/64 QAM generator Weather and shock-resistant enclosure Configuration of channel plans and tests via the TechComplete TPP software Complete QAM analyzer and Analog tester

“Bought as a refurbished unit from local cable provider.”

Brand	jdsu
Model	dsam 2300 xt
