Jdsu Acterna Ttc / T-berd Tb-950 Communications Analyzer Tb950-anlg Tb950-tims

US $389.99

Jacksonville, Florida, United States
Jan 29th

Open on mobile:
QR code

JDSU ACTERNA TTC / T-BERD TB-950 Communications Analyzer TB950-ANLG TB950-TIMS Prev Stop Play Next Only items pictured are included Power Requirements: 90-240 V~, 47-63 Hz, 1 A Software Version: 6.3, 07/23/01 Multiple service testing capabilities combined in a single test instrument Analog and digital testing support Growth-oriented protocol services board and interface module expansion slot for future test access capability TNT Task Based Testing user interface makes routine test set-up simple and intuitive Large graphical LCD allows for two user display screen and a two line results display Applications: Qualify local loop copper wire pairs for both analog and digital services Perform full-duplex monitoring of active T1 and DDS lines Verify and troubleshoot ISDN BRI and PRI services Test the ability to handle incoming calls with PBX/Switch emulation Install and maintain frame relay service from T1, DDS, and Datacom interfaces Perform IP service verification and trouble isolation from a 10BaseT interface. Features: Analog (2W/4W) Interface Module ISDN (BRI/PRI) Option Frame Relay Option DDS Local Loop Option 10BaseT/Ethernet Option Functions: Perform standard T1 BER testing and signal analysis measurements Gain T1/FT1 access for BER testing with standard and advanced stress patterns, as well as built-in T1 smart repeater and HDSL loopcodes Test end-to-end WAN service through DTE/DCE equipment emulation and in-service monitoring Perform TIMS measurements for qualification of voice and data circuits; place, receive calls, and perform signaling event/digit analysis on analog loop start, ground start, and DID voice circuits Verify circuit-switched ISDN BRI voice, data, and D packet services by performing NT1 and LT BERT, or NT1/TE emulation T1 Specifications: Operating Modes: Terminate (TERM), Drop and Insert (D&I), Monitor (MON), Line Loopback (LLB) Framing: ESF, SF, SLC, Unframed, Auto T1 Input: Frequency: 1.544 MHz +/- 5000 Hz Input Impedance: TERM: 100 ohms +/- 5% BRIDGE: 1000 ohms minimum DSX-MON: 100 ohms +/- 5% Operating Range: TERM: +6 dBdx to -35.0 dBdsk cable attenuation DSX-MON: +6 dBdx to -35.0 dBdsk cable attenuation T1 Output: Frequency: 1.544 MHz +/- 7 Hz Line Build Out (LBO): 0, -7.5, -15, -22.5 dB +/- 1 dB at 772 kHz Operating Range: DSX MON: -10 dBdsx to -30 dBdsx resistive attenuation Line Coding: AMI, B8ZS Error Insert Type: BPV, Logic, Frame, L&BPV (Logic and BPV errors) Indicators: Signal Present, Frame Sync, Pattern Sync, B8ZS Detect, AIS (Alarm Indication Signal) and Yellow Alarm Frequency Measurement Specifications: Accuracy: +/- 10 ppm Resolution: 1 Hz Level: Peak to Peak: 20 mV to 12.0 V Positive and Negative Base to Peak: 10 mV to 6.0 V Positive and Negative Base to Peak: -48.0 dBdsx to +6.7 dBdsk Resolution: +/- 1 dB Simplex Current: Range: 10 to 207 mA, and under 10 mA Accuracy: +/- 10% or 2 mA (whichever is greater) Wander: Resolution: 1 UI Accuracy: 1 UI DDS Specifications: Data Formats: Standard DDS and DDS with Secondary Channel Primary Channel Data Rates: 2.4, 4.8, 9.6, 19.2, 38.4, 56 and 64 kbps Secondary Channel Data: Idle, 511, and 2047 BER testing patterns are available Clock Source: Internal Oscillator, Recovered timing from received signal Receive Signal: Connection: OCU DP Mode: RJ-45 pins 1 & 2 DSU/CSU Mode: RJ-45 pins 7 & 8 Monitor Mode: RJ-45 pins 1 & 2 and 7 & 8 Termination Impedance: Balanced, 135 ohm +/- 5 % Bridging Impedance: Greater than 1900 ohms Operating Range: 56 kbps and 64 kbps: +6.0 dB to -45 dB minimum All other data Rates: +6.0 dB to -40 dB minimum Transmit Signal: Connection: OCU-DP Mode: RJ-45: pins 7 & 8 DSU/CSU Mode: RJ-45: pins 1 & 2 Termination Impedance: Output Levels: Balanced, 137 W, +/- 5% Output Levels: 0, -3, -6, and -9 dB of simulated cable attenuation Test Modes: TERMINATE, MONITOR, Line Loop Back (LLB) Emulation Modes: DSU/CSU, OCU-DP or Metallic Simplex Current: Input Level: +/- 30 mA maximum Measurement Range: +/- 26 mA with an accuracy of +/- 10% or 2 mA OCU-DP Mode Current Output: > or = to 4 mA to 20 mA depending on span length Error Insertion: Operation: Single or continuous Error insert type: Logic, BPV, L&BPV, or Frame Loop Response: V.54, DSU/CSU, Disabled Frame Relay Specifications: Test Modes: Terminate, Drop and Insert (T1 Interface Only), Monitor Link Management Analysis: LMI Rev.1, T1.617 Annex D, Auto, None PING Testing: ICMP Echo Test, NLPID Encapsulation ISDN BRI U Interface Specifications: Interface: U Interface with To LT and To NT Devices: NT1 Physical Configuration: Point to Point, Synchronous and Full-Duplex Bit Rate: 160 kbps User Data Rate: 144 kbps Line Coding: 2B1Q Line Rate: 192 kbps Maximum Voltage: +/- 2.5 V 10BASET/Ethernet Specifications: Test Modes: Terminate DHPC Implementation: RFC 2131 PING Testing: ICMP Echo Test Traffic Generation: Load Rate: 1 kbps to 10 Mbps (User Selectable) Packet Length: 70 to 1518 bytes (User Selectable) Analog Module Specifications: Interfaces: Two Bantam connectors: 2-wire alternate Transmit and Receive on the 2W/4W Tx connector, 4-wire simultaneous Transmit on the 2W/4W Tx connector and Receive on the 4W Rx connector Termination Impedance: 135 ohm, 600 ohm, or 900 ohm Loopbacks: Tx VF Loop Up, Tx VF Loop Down, 2713 Hz Loopback Response Level: 10 dB to -30 dB Frequency: 2706 Hz to 2720 Hz Receive Holding Tone: Frequency: 1004 Hz Level: Controllable from +10 dBm to -40 dBm Stability: +/- 0.005 Hz Ring Detection (2 Wire Only): 40 V to 150 V RMS Ringing Signal, 16 Hz to 68 Hz Line Holding Current: 26 mA DC, -8.6 V to -56.7 V (Signaling or Signaling plus TIMS) Dial and Receive Digit Types: DP: Dial Pulse DTMF: Dual Tone Multifrequency MF: Multifrequency (DID only) Datacom Module Specifications: Interface: EIA-232-D: Supports EIA-232-D/V.24/V2.8 - BA, BB, CA, CB, DD, CF, DB, DD, LL, RL, CD, DA and TM EIA-530: Supports EIA-422-B for BA, BB, CA, CB, CC, CD, CF, DA, DB, and DD - Supports EIA-423-B for LL, RL, and TM RS-449: Supports EIA-422-B for SD, RD, RS, CS, DM, TR, RR, RT, ST, and TT - Supports EIA-423-B for LL, RL, and TM (Requires DB25 to DB37 Adapter for EIA-530 connector) V.35/306: Supports balanced clock and data circuits, and EIA-232/V.24/V.28 control circuits Supports 306 for SCT, SCTE, SCR, SD and RD - Supports V.35 for 103, 104, 114, and 115 - Supports V.28 for 105, 106, 107, and 109 X.21: Supports V.11 for R, I, S, T and C Data Rates: EIA-232 Max. Synchronous Data Rate: 128 kbps Max. Recovered Data Rate: 128 kbps RS-449 Terminated: Max. Synchronous Data Rate: 10 Mbps Max. Recovered Data Rate: 512 kbps RS-449 Unterminated Max. Synchronous: with cable characteristics Max. Recovered: 512 kbps EIA-530 Terminated: Max. Synchronous Data Rate: 10 Mbps Max. Recovered Data Rate: 512 kbps EIA-530 Unterminated: Max. Synchronous: Varies with cable characteristics Max. Recovered: 512 kbps. X.21 Max. Synchronous: Varies with cable characteristics Max. Recovered: Varies with cable characteristics. V.35 Max. Synchronous: Varies with cable characteristics Max. Recovered: 512 kbps.V.35-306 Max. Synchronous. Data Rate: 5 Mbps Max. Recovered Data Rate: 512 kbps Test Modes: BERT, Frame Relay Thanks For Checking Out Our Listing. Dont Forget To Visit Our Store As Well!!! http://stores.ebay.com/RefurbNet Paypal and all major credit cards are accepted. Item(s) will only be shipped after completed payment. Sales tax is only applied to buyers in Florida. We offer FREE SHIPPING on over 90% of our listings to the continental U.S. An extra charge will be applied to HI, AK, or PR purchasers. Item will be professionally packed and shipped following payment. All orders will be shipped either the same business day or the next business day. Orders will be combined if necessary. Unfortunately, at this time we are not accepting international customers. Headquartered in Jacksonville, our parent company strives to give new life to technology through the refurbishing, reselling and recycling of computers, telephone systems, computer monitors, and network equipment. Items that do not have a place within our parent company's normal operations are listed for sale on eBay. Therefore, we offer some rather unique items. Take a look at refurb.net. [CONTACTINFO]

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Powers on, no other testing”
