Content on this page requires a newer version of Adobe Flash Player. The Following Items Are Included: JDSU HCU-400 4-Slot Modular PathTrak Controller (BC# 10758) (4) JDSU RPM-2000 Modules (1) JDSU CPU 5500 GigE Module Power Cord RS232 PC Interface Cable Bracket Set JDSU PathTrak HFC Test/Monitoring Solution Installation Guide User Manual On CD-ROM BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! JDSU HCU-400 4-Slot Modular PathTrak Controller With 4 RPM-2000 Modules & A JDSU CPU 5500 GigE Module Self-Contained Data Analysis, Measurements & Storage. For Use With The SDA-5000 Stealth CATV Digital Analyzer Includes Accessories As listed Above! Working Condition: Excellent Condition: Refurbished Warranty: 90 Day Exchange Warranty Features: Modular design Scalable and flexible architecture for large and small hub sites Self-contained data analysis, measurements and storage Easy to integrate into existing LAN Very low data bandwidth required Only one IP address necessary (independent of RPM cards) One year of data storage; no database management required Reliable operation The HCU Modular Controller provides the communications gateway to and from the Master System Controller (Server PC) and data monitoring equipment. In addition, the HCU provides the housing for PathTrak monitoring modules, memory for data storage, and an on-board processor for intelligent analysis and control of monitored data. The HCU communicates to the Master System Controller to notify users of system alarms and status. Users can also initiate contact to the HCU through the Master System Controller to interactively control and view monitoring system data. Largely due to the design of the HCU, the PathTrak Performance Monitoring System is an extremely scalable system, maintaining high performance in large deployments. Modular Platform Provides Scalable Housing The HCU housing is an industry standard VME chassis. Each HCU has a specific number of slots available for PathTrak monitoring system modules and cards (i.e., the RPM1000 spectrum analyzer cards). Users are able to construct a system that contains the number and kind of modules to meet their specific needs today, which reduces initial investment costs. Then, as user network architectures grow and needs change, new modules and capability can easily be added. Intelligence and Data Storage in HCU Improves System Performance Each HCU contains a multi-gigabyte hard drive module for storage of monitored performance data and a powerful single board computer module for intelligent analysis. Once the user establishes and downloads monitoring plans to the HCU, the HCU becomes a completely self-managed unit. With so much on-board processing power so close to the monitoring modules, data storage and analysis is much faster, and more extensive intelligence and higher overall system performance is possible. Local HCU Processing Improves Scalability and Reduces LAN Impact Since all data storage and analysis is performed in the HCU, communication to the Master System Controller (Server PC) is only required to communicate system status and alarms. Thus, multiple HCUs deployed in multiple remote sites can all perform at equally high speed and will not be restricted by communication links to a central PC controller. This also minimizes network traffic over a user’s LAN or data communications networks. PathTrak does not require a dedicated high bandwidth LAN to monitor peak performance. Excellent Reliability After proper setup, the HCU is a completely self managed stand-alone unit. This means it works independent from the LAN. If the LAN has a temporarily outage, the monitoring process still continues. All local processing power is supported by the on-board computer. Because the computer is a VMEindustry type version, the Mean Time Between Failures (MTBF) is much greater than what's expected from standard PC's. Specifications Width 19’ rack mountable Height 4 rack units (6.968 in, 176.9mm) Weight 25 lbs. maximum / 11.5kg Module Capacity 4 available slots for module cards Data StorageCapacity 2 GB Processor Motorola Power PC single board computer CE marked Communication Ports Four serial RS232, one 10/100 baseT Ethernet, one parallel port Power Supply. AC auto-ranging 90-132 VAC 180-246VAC at 47-63Hz Max. Operating Temp 0-50oC Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you! Contact: Test Equipment Store eBay Sales Phone: 1-419-517-6681 Toll Free : 1-800-548-2381 We Ship World Wide! We will attempt to ship your item(s) within 24 hours after payment has been received. To get a real-time shipping quote to your destination, enter your country and zip / postal code information into the shipping calculator and click "Get Rate". Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We Offer Multiple Quantity Price & Shipping Discounts, Email Us If You Are Interested In Larger Quantities. UPS Ground United States USD 0.00 USPS Express Mail International (EMS) Worldwide USD 0.00 We accept credit card payment transactions via the online checkout system! The checkout process is designed so that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through the online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hours (1 Business Day) upon receipt of payment from the winning bidder. (Certain orders may take longer for processing due to comprehensive final service inspections) A Shipment Tracking number(s) will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Tracking number(s) will be provided the same day as order shipment. Thank you ALL MAJOR CREDIT CARDS & PayPal ACCEPTED Reach your goals with Kyozou eBay Selling Tools
