Imperial Hot Plates Open Burners Cast Iron Grates Nat Gas Model Ihpa-1-12

US $558.60

  • Gilbertsville, Pennsylvania, United States
  • Jan 31st
Since it's Inception in 1957, Imperial has remained a family-owned company whose mission is to be the preferred global supplier of high quality, top value cooking equipment to the foodservice industry. Imperial Utilizes highly skilled employees combined with innovative manufacturing processes. Imperial continually invests in state-of-the-art technology and machinery as part of the commitment to future growth. This Provides enhanced efficiencies, lower production costs and consistent top quality equipment. Features PyroCentric burner heads with two rings of flame for even cooking no matter the pan size. PyroCentric burners are 28,000 BTU/hr (8 KW) with a 7,000 BTU/hr. (2 KW) low simmer feature. Cast iron burners are anti-clogging and removable for easy cleaning. No gaskets or screws. Grates are in 12" x 12" (305 x 305) sections to easily lift off for cleaning. Anti-clogging shield designed in the grate protects the pilot from grease and debris. Pots slide easily from section to section. Stainless steel front, sides, and landing ledge. Welded stainless steel seams. Large 5" (127) stainless steel landing ledge. 4" (102) heavy duty stainless steel legs with adjustable feet. One year parts and labor warranty. AGA and CGA design certified, NSF and CE listed. Specifications Brand: Imperial  Model: IHPA-1-12 Gas Supply: Natural Gas Number of Burners: 1 Open Burner Width: 12" (305) Total BTU (KW): 28,000 (8) Shipping Weight (Kg): 45 Lbs. (21) Dimensions(WxDxH): 12" x 31 3/8" x 36" Crated Dimensions: 14"(356)w x 36"(914)d x 35"(889)h. Width: add 2 1/2"(64) to Hot Plate width. Standard Exterior Front, sides, landing ledge and control panel shall be stainless steel. All stainless steel seams shall be welded and finished. Control knobs shall be durable cast metal with a polished chrome finish. Legs shall be 4" (102) stainless steel with adjustable feet. Range Tops Open Burners shall be 28,000 BTU/hr. (8 KW) lift-off PyroCentric burner heads with no gaskets and no screws. There shall be one standing pilot for each burner. Top Grates shall be constructed in 12" x 12" (305 x 305) lift-off sections and be made of heavy-duty cast iron. Cast-in bowl shall direct heat upward. Top grate design shall include an integrated pilot shield. Full width, one piece drip tray shall be removable. Gas  Manifold pressure is 5.0" W.C. for natural gas or 10.0" for propane gas. Manifold size 3/4" NPT. 3/4" pressure regulator supplied with equipment to be installed at time of connection. Specify type of gas and elevation if over 2000 ft. (610 m). Clearance  For use only on non-combustible floors. Legs or casters are required for non-combustible floors; or 2" (51) overhang is required when curb mounted. Provide 0" clearance from non-combustible surfaces and 8" (203) from combustible surfaces. Optional Items 10" (254) stainless steel wok ring Saute burner head Wok burner head Gas shut off valve 3/4" (19) Quick disconnect and flexible gas hose Stainless steel equipment stand 6" (152) casters for equipment stand
