Imer Step-up 120 Spray & Grout Pump 1106098

US $760

Newburgh, New York, United States
May 30th

Open on mobile:
QR code

DETAILS Imer Step-UP 120 Spray & Grout Pump Single Phase The Step-Up 120 is the bigger brother of the famous Mighty Small 50 Spray and Grout Pump. The Step-Up 120 is designed for the applications that need to be pumped and sprayed with more flow and pressure. A built in vertical shaft mixer sits atop the Step-Up 120 and discharges right into the pump for an easy and practical way to fill the hopper. The 220v 2 h.p., motor and gearbox variation of our Mortarman 120 is ideal to handle the mixing, as it will mix just about any material perfectly. As the mixer is powered by inverter technology it also runs in reverse, which is very helpful when material needs to be broken up. Use almost any material with aggregate size 1/8" with single phase motor. Mix and pump at the same time The Step-Up 120 comes standard with an IM25L stator which can handle up to 1/8 inch aggregate and produce up to 6.6 GPM and 450 PSI of pumping pressure. The Step-Up 120 is made to be towed on the road but also able to pass through 36" doorways. A dual diaphragm maintenance free compressor is used to provide the air flow for spraying applications. Step-Up 120 Features. The Step-Up's rotor/stator is turned by a 3 HP, 220 volt single phase motor using inverter technology. The inverter provides smooth and continuous power even when the electrical source is not ideal. The inverter also aides in starting and controlling the frequency at which the pump operates. This allows the RPM's to range between 30 and 100, enabling the Step-Up 120 to be used for numerous applications and materials. The Step-Up 120 is designed to be an all in one unit with optimum mixer output delivering material into the hopper. It is easy to setup and easy to operate, and does not require special electrical connections or an electrician to hook it up. All the motors combined are just under six horsepower and can operate on 16 Amps of 220 Volt single phase power. Competitor’s pumps with similar output require either three phase power or 72 Amps of single phase. Small, light, easy to own and operate and able to handle 3/8" aggregate, the Step-Up 120 is the number one solution for your pumping and spraying needs. Free shipping from IMER factory warehouse Model IMER Step 120 Voltage/phase 220/single phase Pump motor HP 3 HP Compressor flow rate 9 CFM Compressor HP 1 HP Screw pump RPM (IM25L) Variable from 30 - 100 Max aggregate size (IM25L) 1/8" Max Flow Rate 6.6/0.9 GPM/cf Max Pumping Distance. 130 - 250 ft. material viscosity dependent. Material flow rate 6.6/0.9 GPM/cf Hopper Capacity 4.2 cf (31 gallons) Mixer Capacity 4.2 cf (31 gallons) Mixer Motor 2 hp Weight 870 lbs Dimensions LxWxH 80.3"x32.2"x50.2" Shipping Freight Truck
