Icstation Atmega168pa Development Board Avr Minimum System Core Board Practical

US $310

???, ???, China
Jun 9th

Open on mobile:
QR code

Click to Enlarge Click to Enlarge ICStation ATMEGA168PA Development Board AVR Minimum System Core Board Practical 1.Feature 1).ATMEGA168PA-AU,PicoPower AVR microcontroller technology, with 8K Bytes in system programmable flash, 512 Bytes in system programmable EEPROM, 1K Bytes on-chip SRAM. 2).High-performance, Low-power AVR® 8-bit Microcontroller. 3).Advanced RISC Architecture. 4).High Endurance Non-volatile Memory segments. 2.Application It can be used in module testing,chip researching and learning. It can be used as main control board. It can be used to learn AVR Microcontroller. It can be used to research the ATMEGA8A 3.Parameter JTAG: Debugging Interface Dx: Data Interface 5V: 5V power supply 3.3V: 3.3V power supply 4.Mechanical drawing Unit: mm 5.Function High Performance, Low Power AVR®8-Bit Microcontroller Advanced RISC Architecture ? 131 Powerful Instructions ? Most Single Clock Cycle Execution ? 32 x 8 General Purpose Working Registers ? Fully Static Operation ? Up to 20 MIPS Throughput at 20 MHz ? On-chip 2-cycle Multiplier High Endurance Non-volatile Memory Segments ? 4/8/16/32K Bytes of In-System Self-Programmable Flash program memory ? 256/512/512/1K Bytes EEPROM ? 512/1K/1K/2K Bytes Internal SRAM ? Write/Erase Cycles: 10,000 Flash/100,000 EEPROM ? Data retention: 20 years at 85°C/100 years at 25°C(1) ? Optional Boot Code Section with Independent Lock Bits In-System Programming by On-chip Boot Program True Read-While-Write Operation ?Programming Lock for Software Security Peripheral Features ? Two 8-bit Timer/Counters with Separate Prescaler and Compare Mode ? One 16-bit Timer/Counter with Separate Prescaler, Compare Mode, and Capture Mode ? Real Time Counter with Separate Oscillator ? Six PWM Channels ? 8-channel 10-bit ADC in TQFP and QFN/MLF package Temperature Measurement ? 6-channel 10-bit ADC in PDIP Package Temperature Measurement ? Programmable Serial USART ? Master/Slave SPI Serial Interface ? Byte-oriented 2-wire Serial Interface (Philips I2C compatible) ? Programmable Watchdog Timer with Separate On-chip Oscillator ? On-chip Analog Comparator ? Interrupt and Wake-up on Pin Change Special Microcontroller Features ? Power-on Reset and Programmable Brown-out Detection ? Internal Calibrated Oscillator ? External and Internal Interrupt Sources ? Six Sleep Modes: Idle, ADC Noise Reduction, Power-save, Power-down,Standby,and Extended Standby I/O and Packages ? 23 Programmable I/O Lines ? 28-pin PDIP, 32-lead TQFP, 28-pad QFN/MLF and 32-pad QFN/MLF Operating Voltage:? 1.8 - 5.5V Temperature Range:?-40°C to 85°C Speed Grade:? 0 - 4 MHz@1.8 - 5.5V, 0 - 10 MHz@2.7 - 5.5.V, 0 - 20 MHz @ 4.5 -5.5V Power Consumption at 1 MHz, 1.8V, 25°C ? Active Mode: 0.2 mA ? Power-down Mode: 0.1 ?A ? Power-save Mode: 0.75 ?A (Including 32 kHz RTC) For more quantity,please contact us. 1) We accept PayPal payment ONLY. inkfrog terapeak inkFrog Analytics

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	ICSTATION
Type	Does not apply
Model	Does not apply
Color	Does not apply
MPN	Does not apply
Material	Does not apply
Country/Region of Manufacture	China
UPC	Does not apply
