HP Agilent 54657A Measurement Storage Module: GPIB, FFT + more for 54600 Series, US $3600 – Picture 0
HP Agilent 54657A Measurement Storage Module: GPIB, FFT + more for 54600 Series, US $3600 – Picture 0

Hp Agilent 54657a Measurement Storage Module: Gpib, Fft + More For 54600 Series

US $3600

  • Austin, Texas, United States
  • Nov 26th
Open on mobile:
QR code
Tested HP 54657A add-on module for 54600 series oscilloscopes.  I used this with my 54600B scope and did not notice any issues. Cosmetically it's also in pretty good shape.  Feature set description copied from HP / Agilent / Keysight: The Agilent 54657A, 54658A, and 54659B Measurement/Storage Modules provide additional measurement and storage capabilities to the Agilent 54600–Series oscilloscopes. The 54657A has a GPIB interface and the 54658A has a RS-232 interface. The 54659B has a RS-232 interface plus an additional parallel output connector which allows the module to be connected to both an RS-232 controller and a parallel printer at the same time.  The main features are:  • Full Programmability.  • Hardcopy output.  • Three additional automatic voltage measurements (amplitude, preshoot, and overshoot).  • Two additional automatic time measurements (delay and phase angle). User defined measurement thresholds of 10%/90%, 20%/80%, or selected voltage levels.  • Two additional cursor measurements (voltage in percent and time in degrees).  • Two additional cursor measurement sources (math function 1 and 2).  • Waveform math functions (addition, subtraction, multiplication, differentiation, integration, and FFT)  • Time and date tagging of hard copy and and nonvolatile memories. Three uncompressed nonvolatile trace memories.  • Additional 64K of nonvolatile trace memory (with data compression) for up to 97 more trace memories..  • Unattended waveform monitoring by use of mask templates.  • Built-in automatic mask generation and mask editing capabilities. Additional product literature and support can be downloaded from Keysight.
