Hp 8566a/b Spectrum Analyzer 100hz To 22gz. Tested! Calibrated On 3/20/2016

US $2200

Kissimmee, Florida, United States
Nov 5th

Open on mobile:
QR code

Calibration Cables are included ($400 Value). The HP 8566A (introduced in 1978) is a high-performance spectrum analyzer that operates from 100 Hz to 2.5 GHz in the low frequency band, and 2 to 22 GHz in the preselected microwave band. It uses a synthesized LO to provide accurate frequency tuning and an internal microcomputer to automate controls and provide useful operating features. The standard 8566A is equipped for HP-IB operation. Frequency range: 100 Hz to 2.5 GHz, 2 to 22 GHz Frequency resolution: 10 Hz to 3 MHz Spectral purity: <-78 dBc, 300 Hz offset, 5.6 GHz Amplitude range: -137 dBm to +30 dBm Scale resolution: 10, 5, 2, 1 dB/div or linear with amplitude in dBm, dBmV, dBµV, V Dynamic range: Up to 90 dB Flatness: ±2.2 dB HP / Agilent 8566B 22 GHz Microwave Spectrum Analyzer You are bidding on an HP / Agilent 8566A & 8566B 22 GHz Microwave Spectrum Analyzer. The The Agilent 8566B is a high-performance spectrum analyzer for bench and ATE system use. The Agilent 8566B has a frequency range from 100 Hz to 22 GHz that can be extended to 325 GHz using external mixers. The exceptional frequency stability of the Agilent 8566B makes it possible to make measurements with a 10 Hz resolution bandwidth. This narrow resolution bandwidth yields sensitivities to -135 dBm. Excellent frequency stability, sensitivity, and frequency-reference accuracy combine to allow very accurate measurement of small signals in the presence of large ones. This spectrum analyzer fits into many applications, such as EMC testing, broadband signal surveillance, and component stimulus-response testing. This unit is in good condition, has been fully tested and comes with a 5 day right of return. Please review pics and text carefully before bidding to confirm accuracy of description.
