High Speed Pressure Controller/calibrator Mensor Cpc 3000. Range -15 To 100psig

US $5,000.00

  • San Jose, California, United States
  • Jun 9th
Applications Industry (laboratory, workshop and production) Transmitter and pressure gauge manufacturers Calibration service companies and service industry Research and development laboratories Special Features Pressure ranges -1 ... 100 bar / -1 ... 1,500 psi Control speed < 3 s Control stability 0.004 % FS Precision up to 0.015 % IS (IntelliScale) Accuracy up to 0.025 % IS (IntelliScale) Description Design With its compact design, its exceptionally reliable and patented control unit, and available pressure ranges of -1 … 100 bar / -1 ... 1,500 psi, the model CPC3000 high-speed pneumatic pressure controller offers a wide range of application possibilities. The instrument is available as a desktop instrument or as a 19" rack-mounted unit. Application Since the controller offers an accuracy of up to 0.025 % IS-50, and the pressure can be controlled extremely quickly, it is particularly suited as a production tool for gauge and/or transmitter manufacturing or as a factory/working standard for the verification or calibration of all types of pressure measuring instrument. Functionality The large touchscreen and the simple menu navigation guarantee maximum ease-of-use. In addition, its operability is further supported by the availability of a large number of menu languages. Depending on the application, the operator can choose between three input functions or menu blocks: Numeric keypad for the precise input of the pressure value (set point) which will be controlled. STEP button block (max. 12). Each button thus represents a defined pressure value (these pressure steps are freely definable via the menu). JOG buttons: with these, the three least significant decimal places of the current pressure value can be raised or lowered by a digit. Software In addition to the WIKA-CAL calibration software, which enables the convenient calibration of pressure measuring instruments and the generation of test certificates, individual test programmes can also be created, e.g. within LabVIEW®. For the serial command formats, the Mensor standard, SCPI or further optional instruction sets are available. Complete test and calibration systems On request, complete mobile or stationary test systems can be manufactured. There is an IEEE-488.2, RS-232 or USB and an Ethernet interface for communication with other instruments, and thus the instrument can be integrated into existing systems.
