Hi-precision 0.05% Digital Lcr Meter 10hz-300khz Comparator Tft Lcd Usb At2818

US $2,362.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

AT2818 Precision LCR Meter AT2818 adopts true-color TFT-LCD and English operation interface (Chinese is also available). AT2818 (Rev B2.0) has been upgraded into continuous frequency with the resolution of 0.001Hz. Four parameters can be measured at the same time by AT2818, any parameters can be set arbitrarily. Both main & sub parameters can be displayed in 6 dgt after the improvement. AT2818 can not only scan 10 kinds of frequency or voltage level, but also correct three groups of user frequency so as to improve the accuracy. Feature: TFT-LCD Display Correction: OPEN and SHORT Comparator Function: 10 files,14 bins: P1~P9,NG,AUX, HI, IN, LO Interface: RS232C and Handler Optional Interface: USB-Disk and USB-232 Test signal monitor: Vm and Im Avarage rate: 1~200times Measurement Terminal: 5 terminals Key lock function Specification: Parameters Cs-Rs,Cs-D,Cp-Rp,Cp-D,Lp-Rp,Lp-Q,Ls-Rs,Ls-Q,Rs-Q,R-X,Z-?rad,Z-?deg Monitor Parameters Z, D, Q, ?r, ?d, R, X, G, B, Y, Vac, Iac, ?, ?% Accuracy 0.05% ±5 Frequency 10Hz~300kHz Display Range L: 0.00001?H - 999999H C: 0.00001pF - 999999?F R,Z: 0.00001? - 99.9999M?W D,Q: 0.00001 - 999999 ?(deg): -90.0000°- 90.0000°° ?(rad): -3.14159 – 3.14159 ?%: -999.999% - 999.999% Source Resistance 30? 50? 100? Range Automatic, Manual, and nominal, 9 ranges Display Max 6 digital, principle parameter: 999999; sub parameter:999999; monitor parameter: 999999 Signal Level 0.01V - 2.00V (10mV Step) Speed 30t/s, 10t/s, 6 t/s, 3 t/s 1-256 times average is available Comparator 14-bin sorting, 10-bin GD, 1-bin NG, 1-bin AUX, 2-bin principle parameter NG; Count Function: Max - 999999 List Test 10 group frequency and level scanning measurement Adjustment Open & Short circuit sweep frequency reset, 3 point frequency reset and load calibration. Files 10 group files to save user's setting, 1 group to save system data real-time Interface RS232C, ExHandler interface, standard configuration USB Disc interface (article 10000 data)

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	AT2818
Country/Region of Manufacture	China
MPN	AT2818
