Heinrich 5c Air Collet Fixture

US $570

  • Campbell, California, United States
  • May 30th
 Heinrich 5C Air Collet Fixture and foot pedal. I bench tested fixture with 100psi compressed air and all works, it clamps and releases. Uses Standard 5-C type collets up to 1-1/8" diameter to hold round, hexagonal and square workpieces. Can also be used with step chuck collets and expanding chucks for internal gripping. Double acting, piston type air cylinder develops holding power 18 times air line pressure Maximum operating pressure: 120 psi Has 1-7/64" hole completely through unit for bar feeds or dropping finished parts Two lugs provided for mounting Knurled collet holder is hardened and precision ground Base of fixture is relieved for chip removal and coolant flow - U.S. Shipping Only
