Hardinge Hv-4n Horizontal / Vertical 5c Workholding Index Fixture / Indexer

US $260

  • Merrimack, New Hampshire, United States
  • May 28th
Open on mobile:
QR code
RETAIL PRICE NEW IS OVER $4000.  This is an excellent used Hardinge HV-4N Indexer. Hardinge Collet Index Fixtures provide a quick and accuragte method of chucking and indexing work. Fixtures are planned to be applied interchangeably on the sub-base or on the table of milling machines, grinders, shapers, and drill presses.  The spindle takes 1" capacity 5C Collets and has a hardened and ground index plate with 24 holes to give 15 degree spacings. Index holes and index pin have 8 degree included angle taper for positioning and locking. The index pin is spring backed for quick location in the index holes.  In addition the HV-4N has a hardened and ground index plate with preselecting arrangement. A collet closer with 100 to 1 leverage to facilitate rapid chucking of work on a production basis. Ratchet device for rotating the spindle rapidly when indexing. Base for operation in either a horizontal or vertical position. Specifications: Spindle Type: 5C Nose Thread: 2-3/16" - 10 TPI Distance from Base to Center (set horizontally): 4" Base to Spindle Nose (set vertically): 8" Overall Dimensions (set horizontally): 10" x 8" x 8" tall Comes as shown in pictures.
