Hantek 6022bl Pc Based Usb Digital Portable Oscilloscope + 16 Chs Logic

US $790

USA, United States
May 28th

Open on mobile:
QR code

Hantek 6022BL PC Based USB Digital Portable Oscilloscope + 16 CHs Logic Analyzer, 48MS/s Real-time Sampling, 20MHz Bandwidth, FFT Item Description Excellent industrial design-the same anodised aluminium casing as iPad, which is not only beautiful and tasteful but also greatly enhanced the hardness of aluminum alloy surface, and has good heat resistance and strong wearability. Standard USBXITM interface, easily inserts into USBXITM housing to make up a combination instrument. USB2.0 interface, no external power source required, easy to use. Be suitable for notebook computer, product line maintenance, be used easily on business. High performance, . Features Features * Operating System: Windows8, Windows 7, Windows NT, Windows 2000, Windows XP, VISTA. * 23 measurement functions, PASS/FAIL Check, be suitable for technical application. * Waveform average, persistence, intensity, invert, addition, subtraction, multiplication, * division, X-Y plot. * Save waveform in the following: text file, jpg/bmp graphic file, MS excel/word file. * One computer can connect many DSO, extend channel easily. * PID/VID Second Design instance. Specifications * Memory Depth: 1M * Rise Time: 17.5ns * Time Base Precision: ?50ppm * Time Base Range: 4ns/div-1h/div (Step by1-2-4) * Input Impendence: 1M? 25pF * Input Sensitivity: 10mV/div?5V/div? * Vertical Resolution: 8Bit * Vertical Position Range: 10mV ~ 5V/div @ x1 probe; 100mV ~ 50V/div @ x10 probe; 1V ~ 500V/div @ x100 probe; 10V ~ 5KV/div @ x1000 probe * DC Accuracy: ?3% * Bandwidth Limited: 20MHz * Trigger Type: Edge, Alternative * Trigger Source: CH1, CH2, EXT, EXT/10 * Math : +,-,x,?,FFT, Invert * Cursor Measurement: Cross, Trace, Horizontal, Vertical * Auto Measurement: Vpp, Vamp, Vmax, Vmin, Vtop, Vmid, Vbase, Vavg, Vrms, Vcrms, Preshoot, Overshoot, Frequency, Period, Rise Time, Fall Time, Positive Width, Negative Width, Duty Cycle Logic Analyzer * Max. Impendance: 1M?(C=7.5pF) * Max. Voltage: 0V~5.5V * Max. Sample: 48M * Bandwidth: 10MHz * Compatible Input: TTL, LVTTL, CMOS * Memory Depth: 1M/CH Additional Information Manufacturer: Hantek Shipping Weight: 170 Product Dimensions: Width: 6.70 Length: 9.40 Height: 3.00 Shipping Details Depending on your location and on package weight, items will be shipped by USPS or UPS. All stock is at our USA warehouses. Most orders ship within 24 hours of processing your payment unless stated differently. Check our feedback to see how our customers love the FAST shipping we offer! Shipping is always free! 30 Days Return & Refund Policy We provide a 30 days return/exchange policy for our products. The buyer can choose between a refund or an exchange to his/her product. In case of defectives found, only factory defects are accepted as the reason of return. The package of the returned item(s) must be completely intact, and all accessory(s) inside the package must be original and in perfect condition. We do not cover the postage costs for returned defective items. Items returned must be received within 30 days from purchase. No refund or replacement is issued after this period of time. Please allow up to 7 working days for your return to be processed after it is received by us. We are extremely fair, and in the rare event of something out of the ordinary happening, we will gladly work with you to find a solution. Our Guarantee Your satisfaction is guaranteed! We offer a 100% Satisfaction Guarantee on all sales. If you are not happy with your purchase for any reason, please contact us within seven days of receipt of your item, or email us to share your concerns. As mentioned before we are extremely fair and will happily work with you to find a solution to any problem. As you can tell from our feedback, pretty much every single one of our customers is a happy one. So in the rare case something does go wrong, before leaving a negative feedback, contact us so we can help you and make things right! About Us We sell on eBay since 2006. We are based in the USA and ship from our own warehouses. Our products are a 100% authentic and all brand new. We work with the biggest suppliers in the US to bring you the best quality items you can get! We guarantee to provide the best service you have ever seen before Please see our other items Automotive Baby Camera & Photo Clothing Electronics Health & Personal Care Home & Kitchen Home Improvement Kitchen & Dining Office Products Shoes Sports & Outdoors Toys & Games Feedback Profile Other Auctions
