Haas Quad-spindle T5c4 Collet Tilting 2-axis Rotary.

US $12000

  • Auburn, California, United States
  • Jun 6th
Open on mobile:
QR code
HAAS T5C4 Specifications SPINDLE – A (TILT) S.A.E. METRIC Max Speed 0.001 to 60 °/sec  0.001 to 60 °/sec Max Torque 210 ft-lb  285 Nm Runout Max 0.0005 "  0.013 mm Backlash 30 arc-sec   30 arc-sec  Center Height 6.000 ±0.001 "  152.40 ±0.03 mm Gear Ratio 90:1    90:1  Timing 2:1    2:1  Brake Torque @ 100 psi/6.9 bar 200 ft-lb  271 Nm SPINDLE – B (ROTARY) S.A.E. METRIC Number 4   4  Max Speed 0.001 to 200 °/sec  0.001 to 200 °/sec Max Torque 25 ft-lb  34 Nm Nose Thread 2 3/16" - 10   Runout Max 0.0004 "  0.010 mm Backlash 50 arc-sec   50 arc-sec  Center Height 6.000 ± 0.001 "  152.40 ± 0.03 mm Gear Ratio 60:1    60:1  Collet size std 5C (1/64 - 1 1/16) "  std 5C 0.4 - 27 mm INDEXING – A (TILT) S.A.E. METRIC Max Rotation/Step ±120 °  ±120 ° Resolution 0.001 °  0.001 ° Accuracy (±) 15 arc-sec   15 arc-sec  Repeatability 10 arc-sec   10 arc-sec  Worm Gear Dia 6.3 "  160 mm INDEXING – B (ROTARY) S.A.E. METRIC Max Rotation/Step 999.999 °  999.999 ° Resolution 0.001 °  0.001 ° Accuracy (±) 60 arc-sec   60 arc-sec  Repeatability 10 arc-sec   10 arc-sec  Worm Gear Dia 2.8 "  71 mm GENERAL – A (TILT) S.A.E. METRIC Air Pressure Max 120 psi  8.3 bar Operating Temp (max ambient) 100 °F  38 °C Duty Cycle full/low speed 50/100 %  50/100 % Power Required – 1-Axis Control 115 VAC ± 10% @ 15 A   115 VAC ± 10% @ 15 A  GENERAL – B (ROTARY) S.A.E. METRIC Air Pressure Max 120 psi  8.3 bar Operating Temp (max ambient) 100 °F  38 °C Duty Cycle full/low speed 75% full speed   75% full speed  Power Required – 1-Axis Control 115 VAC ± 10% @ 15 A   115 VAC ± 10% @ 15 A  WEIGHT S.A.E. METRIC Table 520  lb  236 kg Brushless Control – 1-Axis 14.2  lb  6.4 kg
