Gy 9dof Mpu-9150 3 Axis Gyroscope+accelerometer+magnetic Field #3068378

US $65

  • Shanghai, China
  • Jun 9th
gy 9dof mpu-9150 3 axis gyroscope+accelerometer+magnetic field   Product Description:    The MPU-9150 is the world’s first 9-axis MotionTracking device designed for the low power, low cost, and high performance requirements of consumer electronics equipment including smartphones, tablets and wearable sensors. And guess what? You get to play with it.    This breakout board makes it easy to prototype with the InvenSense MPU-9150 by breaking out all the pins you need to standard 0.1" spaced headers. The board also provides I2C pullup resistors and a solder jumper to switch the I2C address of the device.    The MPU-9150 is a System in Package (SiP) that combines two chips: the MPU-6050, which contains a 3-axis gyroscope, 3-axis accelerometer, and an onboard Digital Motion Processor (DMP) capable of processing complex 9-axis MotionFusion algorithms; and the AK8975, a 3-axis digital compass. The part’s integrated 9-axis MotionFusion algorithms access all internal sensors to gather a full set of sensor data. The part is offered in a 4x4x1mm LGA package and is upgrade-compatible with the MPU-6050 integrated 6-axis MotionTracking device, providing a simple upgrade path and making it easy to fit on space constrained boards.    Documents: Schematic Eagle Files Example Code Datasheet (MPU-9150)   Features: 10,000g shock tolerant. Full Chip Idle Mode Supply Current: 8?A. I2C Pullup Resistors populated on board. 400kHz Fast Mode I2C serial host interface. Solder Jumper for Switching LSB of I2C Address. Tri-axis compass with a full scale range of ±1200?T. All Pins Broken Out to Standard 0.1" Spaced Headers. Gyro operating current: 3.6mA (full power, gyro at all rates). VDD Supply voltage range of 2.4V–3.46V; VLOGIC of 1.8V±5% or VDD. On-chip timing generator with ±1% frequency variation over full temperature range. Tri-Axis accelerometer with a programmable full scale range of ±2g, ±4g, ±8g and ±16g. Accel low power mode operating current: 10uA at 1Hz, 20uA at 5Hz, 70uA at 20Hz, 140uA at 40Hz. Gyro + Accel operating current: 3.8mA (full power, gyro at all rates, accel at 1kHz sample rate). Digital-output 9-axis MotionFusion data in rotation matrix, quaternion, Euler Angle, or raw data format. Tri-Axis angular rate sensor (gyro) with a sensitivity up to 131 LSBs/dps and a full-scale range of ±250, ±500, ±1000, and ±2000dps. Gyro + Accel + Compass + DMP operating current: 4.25mA (full power, gyro at all rates, accel at 1kHz sample rate, compass at 8Hz rate). Reduced settling effects and sensor drift by elimination of board-level cross-axis alignment errors between accelerometer, gyroscope, and compass. lpsiiak sijpidk qyklede MPI Buyer should pay within 7 days after purchase. We only accept payment via PayPal. Our team focuses on providing high quality products with reasonable price and tries its best to keep transactions as simple as possible. Please be confident of and enjoy your shopping here! Please feel free to contact us via eBay message system or email.
