Gw Instek Gfc-8010h Frequency Counter; 10hz To 120mhz

US $240

Bellmore, New York, United States
Jan 29th

Open on mobile:
QR code

I bought this Frequency Counter in May, 2014 to test the frequency on a standby generator which had a problem. By the time went to use it, the generator would not start, and I therefore could not use the Frequency Counter. I eventually replaced the generator, and I have no need for this instrument. The box was opened to take the pictures, but the Frequency counter was never used. Contains all accessories that came with it (manual, power cord. test leads, and original box and packing material). I will also enclose a copy of the original invoice I received when I purchased it for purpose of the remaining 2 year warranty. Below is the specs as provided by the manufacturer:Digital Frequency Counter FEATURES Frequency and Period measurement 1Hz ~ 120MHz range 8 Digits Display (0.3" LED) Over-Flow Indicator 15mVrms High Sensitivity 5 PPM High Stability Timebase Low Pass Filter Function GFC-8010H (120MHz) SPECIFICATIONS Display 8 digits with Hz, kHz, MHz, GHz, S, mS, ?S, nS and overflow Gate Time 0.1S, 1S, 10S switch selectable Accuracy +(1 digit + Timebase accuracy) Input Sensitivity 10Hz ~ 60MHz < 15mVrms 60MHz ~ 100MHz < 20mVrms 100MHz ~ 120MHz < 30mVrms Impedance 1MW//35pF Coupling System AC Coupling Max Input Voltage 150Vrms Time Base Oscillation Frequency 10MHz Aging Rate +1 PPM per month Temp. Stability 25°C+5°C:+5 ppm Resolution The maximum resolution for frequency measurement is 100nHz for 1Hz and 0.1Hz for 100MHz input respectively, and for period measurement is 10nS for 1Hz and 0.1fS (f=10-15) for 100MHz input respectively. GFC-8010H Power Source AC 100V/120V/220V/230V ±10%, 50/60Hz Accessories Instruction manual, Power cord, Test Lead GTL-101 Dimensions & Weight 230(W) x 95(H) x 280(D) mm, Approx. 1.7kg Update : 2000/11/21 GFC-8010H Generators / Counters/Frequency Counters Template Frequency Range Min 10 Hz Frequency Range Max 120 Mhz (0.12 Ghz) Frequency Functions Frequency, Period Triggers No Digit Display 8 Digit Display 8 Digits Display (0.3"LED) Type of Time Base Oscillation Frequency 10MHz Aging Rate +1 ppm per month Temperature Stability 25°C + 5°C:+5 ppm

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	GwInstek
MPN	01FC8091HOOS
Model	GFC-8010H
