Global Specialties 2001a Function Generator, 0.2hz To 200 Khz Frequency

US $247.59

USA, United States
Jun 9th

Open on mobile:
QR code

Home About Us Feedback Newsletter Shop Categories Arts Crafts & Sewing Automotive Baby Beauty Camera & Photo Electronics Health & Personal Care Home & Kitchen Home Improvement Kitchen & Dining Office Products Sports & Outdoors Toys & Games Store Newsletter! Add my Shop to your Favourites and receive my email newsletters about new items and special promotions! General Interest Global Specialties 2001A Function Generator, 0.2Hz to 200 kHz Frequency Description The Global Specialties model 2001A is a 200Khz function generator housed in a rugged steel enclosure. The 2001A is ideally suited for educational applications due to its durability and low cost. The 2001A has TTL, sine, square and triangle wave outputs, as well as DC offset controls and external sweep input. The Global Specialties 2001A is capable of outputting 10 Volts pk-pk into and open circuit and 5 Volts pk-pk into 600 ohm. Two separate outputs- one variable, one fixed TTL level. Use TTL output to synchronize oscilloscopes, digital circuits and other instruments. 600 ohm impedance and short circuit protection. Continuously variable frequency from 0.2 Hz to 200kHz, with 10:1 calibrated vernier and six decade ranges. Sweep frequency over 100:1 range with external 0 to +/-10V signal. Two output: Function out, TTL-DC coupled, BNC connector. Amplitude: 4 selectable ranges - 1mV to 10mV p-p, 10 mV to 100mV p-p, 100mV to 1V p-p,1V to 10Vp-p (open circuit). DC Offset: zero when feature not selected, variable -5V DC to +5V DC into open circuit when selected; total AC (signal) plus DC (offset) output limited to +/-10V p-p open circuit +/-5V p-p into 600 ohms. Drive: Standard TTL-level square wave (in all modes), buffered to drive 10 TTL loads, rise/fall time less than 25nsec, synchronous with Function outputs. Sweep input: DC coupled, BNC connector. Impedance: 30 Kohms. Sensitivity: 0 to +/-10V input sums with voltage at frequency vernier to sweep output frequency to 100:1; linear sweep range 10:1, maximum in +/-12V. Frequency range: 0.2Hz to 200KHz set with a continuously variable 10:1 frequency vernier, marked in 45 divisions and 6 decade ranges, calibrate to +/-5 percent of setting at 10Hz, 100Hz, 1kHz, 10kHz. Square: +/-1 percent typical time symmetry square wave (calibrated to

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Manufacturer	Global Specialties
MPN	2001A
Brand	Global Specialties
UPC	859338002633
EAN	0859338002633
