Geeetech Sanguinololu V1.3a Bare Pcb For Reprap Prusa Mendel Driver A4988,3d

US $63

Hong Kong, China
Jan 29th

Open on mobile:
QR code

Welcome to my store gsale1213 Description The board is designed to be flexible in the user's power source availability, allowing for an ATX power supply to power the board, or the user can choose to install the voltage regulator kit for use with any power supply 7V-30V.The board features a developer friendly expansion port supporting I2C, SPI, UART, as well as a few ADC pins.All 14 expansion pins can be used as GPIO as well. Notes: The Sanguinololu design is excellent but if you are going to run a heat bed the traces on the Sanguinololu board are NOT sufficient to carry the current required to operate the heat bed. Features 1. Supports multiple communication configurations --2 thermistor connectors with circuitry --2 N-MOSFETs for extruder/bed, or whatever --Selectable 12v(or supply voltage)/5v endstop voltage --Edge connectors enabling right-angle connections --13 Extra pins available for expansion and development -- 6 analog and 8 digital, with the following capabilities, and SD CARD SUPPORT 2. Supports multiple power configurations -- Logic & Motors supplied by ATX power supply (needs molex harddrive connector, and optional 4pin atx connector for additional 12v/supply voltage) -- Logic supplied by USB bus ,optional on-board voltage regulator (molex harddrive connector cannot be installed at the same time) -- Motors supplied by 5mm screw terminal 7-35V 3. Small design - board is 100mm x 50mm (4" x 2") - barely an inch longer than a business card! 4. Sanguino clone, Atmel's ATmega644P - ATmega1284 drop-in compatible!! 5. UART1 (RX and TX) 6. I2C (SDA and SCL) 7. SPI (MOSI, MISO, SCK) 8. PWM pin (1) 9. Analog I/O (5) Package list 1 X Sanguinololu Rev 1.3a bare PCB Payment 1.We accept PayPal only. 2.Payment must be received within 7 business days of auction closing.,or a unpaid case will be opened. Delivery details 1.Standard shipping carrier is ePacket with tracking code for United States address,delivery within 7-14 busienss days. 2.For outside US address,standard shipping carrier is Hong Kong Post without tracking code,delivery within 25-30 business days.We provide a free tracking for order above 45USD.Please contact us if you want to add a tracking code for small orders. 3.Express shipping like DHL,Fedex,UPS,TNT is also avaiable if you are willing to pay extra.DHL is our standard shipping carrier for Expedited shipping,please contact us if you want a different carrier. Terms of sales 1.Customs duties or taxes are buyer's resposibility for all of the listings.Please check with your local customs office if you have any doubts. 2.Please confirm you are putting a correct and complete shipping address here.You are resposible for extra charge if your package been returned because of wrong address.If packages return because of wrong address,you will have to bear extra cost of shipping. Contact us 1.We are always here for you,offering friendly, comprehensive customer service every step of the way. Please follow the good eBay practice to contact us if any doubts and problems.We sincerely hope our item and customer service can give you the BEST BUYING EXPERIENCE on eBay. 2.We believe nothing can solve problems but communication.Please contact our team via ebay message first before leaving any non-positive feedbacks if you feel unhappy here.
