AUCTION IS FOR UNUSED *New in Box* GE FANUC IC-693-MDL-740G OUTPUT MODULE .5AMP 12/24 VDC 16PT POS NEW IN BOX Product Manual 12/24 Volt DC Positive Logic Output - 0.5 Amp, 16 Point IC693MDL740 The 12/24 volt DC Positive Logic 0.5 Amp Output module for the Series 90-30 Programmable Logic Controller provides 16 output points in two groups of eight with a common power output terminal for each group. This output module is designed to have positive logic characteristics in that it sources current to the loads from the user common or positive power bus. The output device is connected between the negative power bus and the module output. The output characteristics are compatible with a wide range of user-supplied load devices, such as: motor starters, solenoids, and indicators. Power to operate the field devices must be supplied by the user. LED indicators which provide the ON/OFF status of each point are located at the top of the module. This LED block has two horizontal rows with eight green LEDs in each row with the top row labeled A1 through 8 (points 1 through 8) and the bottom row labeled B1 through 8 (points 9 through 16). An insert goes between the inside and outside surface of the hinged door. The surface towards the inside of the module (when the hinged door is closed) has circuit wiring information, and circuit identification information can be recorded on the outside surface. The outside left edge of the insert is color-coded blue to indicate a low-voltage module. There are no fuses on this module. This module can be installed in any I/O slot of a 5 or 10-slot baseplate in a Series 90-30 PLC system. Table 7-12. Specifications for IC693MDL740 Rated Voltage 12/24 volts DC Output Voltage Range 12 to 24 volts DC (+20%, 15%) Outputs per Module 16 (two groups of eight outputs each) Isolation 1500 volts between field side and logic side 500 volts between groups Output Current 0.5 amps maximum per point 2 amps maximum per common Output Characteristics Inrush Current 4.78 amps for 10 ms Output Voltage Drop 1 volt maximum Off-state Leakage 1 mA maximum On Response Time 2 ms maximum Off Response Time 2 ms maximum Power Consumption 110 mA (all outputs on) from 5 volt bus on backplane Refer to Appendix B for product standards and general specifications. Discrete Output Modules 7 GFK-0898F Chapter 7 Discrete Output Modules 7-25 IC693MDL740 Output Module Field Wiring Information The following figure provides wiring information for connecting user supplied load devices and power source to the 12/24 volt DC positive logic - 0.5 amp output module. INTERNATIONAL BUYERS - PLEASE NOTE: IMPORT DUTIES, TAXES, AND CHARGES ARE NOT INCLUDED IN THE ITEM PRICE OR SHIPPING COST. THESE CHARGES ARE THE BUYER'S RESPONSIBILITY. PLEASE CHECK WITH YOUR COUNTRY'S CUSTOMS OFFICE TO DETERMINE WHAT THESE ADDITIONAL COSTS WILL BE PRIOR TO BIDDING OR BUYING. PLEASE CONTACT US FOR A SHIPPING QUOTE. WE ARE SELLING IT AS IT IS. WE SELL THIS ITEM IN THE SAME CONDITION AS SHOWN IN THE IMAGE. YOU WILL GET WHAT IS SHOWN IN THE IMAGE. IF ITS NOT SHOWN MEAN YOU WILL NOT GET THAT. PLEASE SEE THE PICTURES CAREFULLY AND UNDERSTAND WHAT YOU ARE BUYING. Check out my other items! HAPPY BIDDING. STILL LOTS OF NEW ITEM COMING IN OUR SHOP. DON'T FORGET TO CHECK IT. IF YOU NEED ANY HEAVY ELECTRIC ITEM INFORM US WE WILL TRY TO FIND IT FOR YOU. PLEASE DO VISIT US FOR OUR NEW LISTING AT A CHEAP PRICE. Return Accepted....... Shipping International Shipping Worldwide Combine Shipping Available depends on the order Shipping by Indian post airmail ,online tracking( only available in some countries), 13-22 business days to arrive. We also provide speed post: Charges extra. (please ask for the charges before buying). I would appreciate if u do not give a low star rating about 'shipping time' at the time of giving feedback. I will be thankful to the buyers who appreciate patience as we will not be responsible for the service transit time, which are provided by the carrier and may vary with the destination, particularly during peak periods. Also Buyer will be responsible for any duty fees required to ship to their country. The scanned booking slip of the packet dispatched thru postal department will be sent to the buyer therefore the buyer has no right to claim for money refund as the packet will be in transit and as claimed we are not responsible for the transit time. Option of Express shipping is also available with tracking no. Please ask for the amount before bidding or buying. Registered mail requires signature on delivery so please ensure there is someone to receive the packet on the delivery address . The item will be shipped within 48 hrs of the confirmed payment received . The item reaches for sure sooner or later. If not look for an note for u r parcel, please contact your nearest local post office within 2 weeks after u receive a mail from us that u r item has been dispatched. Please make sure that u have read and understood all the shipping information before u bid or buy to give an smooth output transaction Also Buyer will be responsible for any duty fees , local taxes required to ship to their country. We will not be held responsible for any wrong or undelivered address . Please make sure that u have read and understood all the shipping information before u bid or buy to give an smooth output transaction
