Gator 1-101-1000 10' 3 Jaw Self-centering Plain Back Chuck

US $1600

  • Duncan, South Carolina, United States
  • Jun 1st
10" 3 JAW SELF-CENTERING PLAIN BACK CHUCK - GATOR With Fine Adjustment • Forged Steel Body • Plain Back Applications Excellent for use where versatility takes precedence over very high load requirements. Features Scroll & jaws hardened and ground. (3) Hardened and ground pinions. A unique micro-adjustment feature enables concentricity to be adjusted within 0.0002" (0.005mm) TIR. (4) Micro-adjustment screws provide .0005" TIR repeatability. Scroll balanced. Benefits Outstanding accuracy, versatility and long life. Product Specifications Item # 63-724-310 Catalog Price $1,151.99 Unit of Measure each Must Buy 1 Country of Origin Import Shipping Restrictions None Brand GATOR Description GATOR Precision Self-Centering Scroll Chuck - CHUCK SIZE: 10" Tool Material: Steel Body 1-101-1000 No. of Jaws 3 Chuck Size 10" Tool Material Steel Body Spindle Plain Back Thru Hole 2.992" Weight 59 lbs. Hole Size 2.992" Material Steel Body Maximum Capacity 9.84" Maximum Rotational Speed 2700 RPM Model # 1-101-1000 Repeatability 0.0004" Series Self-Centering Size 10" TIR Repeatability 0.0004" Powered by Solid Commerce The All-in-One Listing, Inventory & Order Management Solution for Online Merchants
