Galil Motion Controller Dmc-4060 Complete With (2) Xyz 6# Axis Motion Stages

US $1500

Vancouver, Washington, United States
May 29th

Open on mobile:
QR code

Galil DMC-4060 6 axis motion controller Qty - 1 Comes Complete with labeled cables, Manuals, and Software The DMC-40x0 motion controller is Galil's highest performance, stand-alone motion controller. It belongs to Galil's latest generation motion controller family, which accepts encoder inputs up to 22 MHz, provides servo update rates as high as 32 kHz, and processes commands as fast as 40 microseconds-10 times the speed of prior generation controllers. The DMC-40x0 is a full-featured motion controller packaged with optional multi-axis drives in a compact, metal enclosure. The unit operates stand-alone or interfaces to a PC with Ethernet 10/100Base-T or RS232. The controller includes optically isolated I/O, high-power outputs capable of driving brakes or relays, and analog inputs for interfacing to analog sensors. The DMC-40x0 controller and drive unit accepts power from a single 20-80 VDC source. The DMC-40x0 is available in one through eight-axis formats, and each axis is user-configurable for stepper or servo motor operation. With a powerful RISC processor, the DMC-40x0 controllers provide such advanced features as PID compensation with velocity and acceleration feedforward, program memory with multitasking for simultaneously running eight applications programs, and uncommitted I/O for synchronizing motion with external events. Modes of motion include point-to-point positioning, position tracking, jogging, linear and circular interpolation, contouring, electronic gearing and ecam. Like all Galil controllers, programming the DMC-40x0 is simplified with two-letter, intuitive commands and a full set of software tools such as GalilSuite for servo tuning and analysis. Mean Well DRP-480S-24 Power Supply 480W 24V 20A W/ PFC Function Input Type: 1-Phase / Single Phase Output Power: 480 W Input Voltage: 90 VAC to 132 VAC, 180 VAC to 264 VAC Number of Outputs: 1 Output Output Voltage-Channel 1: 24 V Output Current-Channel 1: 20 A Commercial/Medical: Commercial Dimensions: 100 mm L x 227 mm W x 125.2 mm H Mounting Style: DIN Rail Qty = 2 AB5 Driver Amplifier Qty = 6 The AB5 amplifier revolutionizes the driving concept for Nanomotion ceramic servo motors, enabling a frictionless and smooth motion throughout the entire velocity range. At stop, the inherent brake is activated, maintaining the many advantages of brake at power off. Consequently, the control scheme is simplified, facilitating the use of any low cost servo controller to achieve outstanding performance. As a result, in addition to our own FlexDC Motion Controller, the whole range of controllers in the marketplace can be used with Nanomotion motors, as well as generic control algorithms. No custom algorithm is needed to be used with Nanomotion motors. In addition, exceptional control performance is achieved at servo systems, showing robust performance at various working conditions. (2) Complete XYZ Axis Motion Stages (FB-XYZ-1140/XYZ Stage-6# capacity): Each XYZ Axis Stage has: HR4 Nanomotion Motor Qty = 2 HR8 Nanomotion Motor Qty = 1 The HR4 motors are high precision ceramic motors. Designed and manufactured by Nanomotion, Ltd., the HR4 motors, combine unlimited stroke with high resolution in compact dimensions. Among its applications are microscopy, precision motion, robotics, etc. The motors provide a linear response to the input voltage. The operation of the motor and driver resembles that of a DC-motor driven by a voltage amplifier. The HR4-V and HR4-U motors are constructed of materials that have been selected and designed for high vacuum compatibility. The HR8 motors are high precision ceramic motors. Designed and manufactured by Nanomotion, Ltd., the HR8 motors, combine unlimited stroke with high resolution in compact dimensions. Among its applications are microscopy, precision motion, robotics, etc. The motors provide a linear response to the input voltage. The operation of the motor and driver resembles that of a DC-motor driven by a voltage amplifier. The HR8-V and HR8-U motors are constructed of materials that have been selected and designed for high vacuum compatibility. Maximum Allowable Velocity: 250 [mm/sec] Maximum Allowable Velocity: 250 [mm/sec] Dynamic Stall Force: 15 to 18[N] Dynamic Stall Force: 30 to 36[N] Static Holding Force: 14 [N] (reference value) Static Holding Force: 28 [N] (reference value) Non-Energized Stiffness: 2.3 to 2.8 [N/µ] Non-Energized Stiffness: 3.3 to 3.8 [N/µ] Nominal Preload on Stage: 72 [N] Nominal Preload on Stage: 1442 [N] Kf: 2 to 4 [N/Volt command] - Driver and command dependant Kf: 4 to 8 [N/Volt command] - Driver and command dependant Kfv: 60 to 72 [N · sec/m] Kfv: 120 to 144 [N · sec/m] Offset: 1 to 2 [V] - Driver dependant Offset: 1 to 2 [V] - Driver dependant Attainable Resolution: Better than 100 nm Attainable Resolution: Better than 100 nm Nominal Lifetime: 20,000 hours under nominal operating conditions Item will ship by USPS Priority Mail dependent on the size of the order. Seller is not responsible for Sales Tax Seller does not ship internationally. No direct International shipping; only through Ebay Global Center seller express no warranty with this product. This for an "AS IS" condition. Asset Tags: 1281,1347, 1431, & 1446
