Fluke Networks Ts53-a-09 Test Set,data Indicator,dial Tone

US $275.00

  • Colorado Springs, Colorado, United States
  • Jan 29th
 The Fluke Networks TS53 telephone test set, available with various line cord connectors to suit specific applications, is designed for outside plant use to detect dial tone and polarity, place and receive calls, indicate line voltage and current, and verify caller ID and call waiting caller ID services; has a two-way, adjustable-volume speakerphone for hands-free conversation during testing; monitors lines without disrupting service; locks out off-hook testing when high-speed data is detected; and stores up to nine 23-digit telephone numbers which can be speed-dialed via the keypad. It provides tone or pulse operation. The test set has two basic modes of operation: talk mode for off-hook operations including verifying dialing and receiving calls, and monitor mode for on-hook operations including checking for an idle line, listening for line noise, measuring DC voltage on the line, and capturing DTMF (dual-tone multi-frequency) tones to check for proper signaling. In monitor mode, the test set provides a high impedance coupling to monitor lines without disrupting service. When switching to talk mode, the data lockout feature tests the line for high-speed data signals and remains on hook and beeps if such signals are detected. The lockout can be overridden to pull dial tone from a noise line. This test set meets IEC (International Electrotechnical Commission) safety standard 61010-1:2010 and is rated for CAT I installations to 300VDC, which covers equipment on circuits not directly connected to mains. It passes a 20' (6m) drop test and is Ingress Protection certified IP64 for protection against dust and splashed water. The test set can be programmed to turn off automatically after a specified period (default setting is two minutes) of inactivity to conserve battery life, and is made of high-impact plastic. The high-visibility glow-in-the-dark keypad has 12 standard dialing keys including star and pound, and function keys to store, recall, and redial numbers and to pause for accessing a second dial tone when dialing through a PBX (private branch exchange), among other functions. A backlit LCD tracks functions and test status, and displays line voltage from 4 to 140VDC and current from 0 to 120mA. At voltages less than 4VDC and greater than 140VDC, the test set locks out and will not allow off-hook operation. The test set is made of high-impact plastic and turns on automatically when clipped to an active line. A spring-loaded belt clip at the base of the unit provides a secure hold on belt loops and D-rings, and a jack accommodates a headset (sold separately). Additional specifications include various environmental operating conditions. Telephone test sets, also called butt sets, are used by telecom technicians to troubleshoot and maintain copper-wire voice-subscriber lines. Specifications Line current range Off-hook: 10 to 100mA DC resistance Off-hook: 150? (nominal); on-hook: greater than 3M? AC impedance Off-hook: 600? (nominal), 300 to 3,400 Hz; on-hook: greater than 120k?, 300 to 3,400 Hz Rotary dial pulse rate 10 + or – 1 pulses per second DTMF (dual-tone multi-frequency) tone frequency error + or – 1.5% maximum Memory capacity Nine 23-digit speed dial numbers, one redial number Safety ratings Complies with ANSI/ISA (American National Standards Institute/International Society of Automation) 82.02.01 (61010-1) 2004, Canadian Standards Association CAN/CSA-C22.2 No 61010-1-04, UL (Underwriters Laboratories) 61010-1 (2004), and IEC (International Electrotechnical Commission) 61010-1:2010 for CAT I, 300VDC, pollution degree 2 Agency certifications and standards met CE (European Conformity) marking; conforms to relevant Australian EMC requirements and Canadian Standards Association standards Power source Shared line power; 9V alkaline battery (included) Dimensions 211 x 81 x 66mm/8.3 x 3.2 x 2.6 inches (H x W x D) Weight 0.53kg/1.16lb. *H is height, the vertical distance from the lowest to highest point; W is width, the horizontal distance from left to right; D is depth, the horizontal distance from front to back. Datacom and telecom installation and test devices, such as toners and test sets, check cabling and wiring to help ensure proper connections and operation. Tone generator and probe sets, also called toners, are used to locate, trace, and isolate cables in copper media networks. Telephone test sets, also called butt sets, are specialized telephones that connect to telephone lines to check for proper operation and to isolate trouble. Some test sets incorporate a TDR (time-domain reflectometer) and toner for determining cable length and locating faults. While certain devices may be used on live networks, others are only suitable for inactive networks. Field technicians and installers use these devices to set up, maintain, and troubleshoot datacom and telecom cabling within a building or in outside plant (OSP) applications. Fluke Networks, a division of Fluke Corporation, manufactures tools and software for network deployment, performance management, and troubleshooting. The company, founded in 1992, is headquartered in Everett, WA. What's in the Box? Fluke Networks TS53 Pro telephone test set 9V battery Instructions
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand FLUKE NETWORKS
Display Backlit LCD
ManufacturerPartNumber TS53-A-09
Measures Voltage, Current
SKU G4744485
Waterproof IP64
Application VDV
Data Safe Monitor Yes
Connector Type ABN/PP
Dialing Method Tone and Pulse
Includes Caller-ID w/ Call Waiting,2-way Speakerphone
Line Polarity Indicator Yes
Item Test Set
Package Quantity 1
