Fluke 123/003s Industrial Scopemeter With Scc120 Kit, 20mhz Frequency

US $3700

USA, United States
Jun 4th

Open on mobile:
QR code

Fluke 123/003S Industrial ScopeMeter with SCC120 Kit, 20MHz Frequency DETAILS Handheld unit combines a two-channel digital oscilloscope for viewing electrical signals with a digital multimeter for measuring voltage, resistance, capacitance, frequency, and duty cycle The oscilloscope's real-time sample rate is 25MS/s and record length is 512 points per channel for acquiring waveforms True RMS multimeter provides accurate readings when measuring linear or non-linear loads, regardless of waveform 2.83" monochrome LCD with a backlight for visibility in low light Meets European Standard (EN) safety standard 61010-1 and is rated for CAT III installations to 600V SPECIFICATIONS The Fluke ScopeMeter series 120 is a handheld electrical test device that combines a two-channel digital oscilloscope for viewing electrical signals with a true RMS, manual- and auto-ranging digital multimeter on each input for measuring AC and DC voltage to 1,250V, resistance to 50M?, capacitance to 500?F, frequency to 50MHz for Fluke 123 models and 70MHz for Fluke 124 models, and duty cycle from 2% to 98%. The oscilloscope has a real-time sample rate of 25MS/s and a record length of 512 points per channel for acquiring waveforms. Automatic and cursor measurement parameters allow an in-depth analysis of waveforms, and edge and video triggers allow isolation of specific signals. The oscilloscope's advanced automatic triggering recognizes signal patterns and automatically optimizes triggering, timebase and amplitude settings. It has an optical port for attaching a Fluke ITP120 probe (sold separately) for external triggering. The 5,000-count, true RMS (root mean square) multimeter provides accurate readings when measuring linear or non-linear loads, regardless of waveform. It has two ranging modes: manual, which allows the user to select the operating range, and auto, which automatically selects the appropriate operating range. The relative function allows a measurement to be set as a reference value and displays subsequent measurements as a positive or negative deviation from that value, the touch-hold mode captures a stable reading, and the data-hold function freezes a reading on the display to aid documentation. A continuity buzzer confirms that the circuit conducts electricity, and a diode check detects whether a circuit?s diodes are working properly. Setups and screen shots?up to 10 for the 20MHz models and 20 for the 40MHz models?can be stored in the internal memory. A TrendPlot chart recorder graphs readings from both the oscilloscope and multimeter functions of the minimum and maximum values over time. The recorder can be programmed from 15 seconds per division over 120 seconds to 2 days per division over 16 days. Additional specifications include a rise time of 17.5ns for the 20MHz models and 8.75ns for the 40MHz models, and various triggering features. The unit has a 2.83" monochrome LCD with a resolution of 240 x 240 pixels for viewing waveforms and measurements, and a backlight for visibility in low light. A multimeter is an electrical testing tool for measuring multiple properties of an electrical circuit to verify proper operation or diagnose problems. The unit has an optically isolated RS-232 interface for connecting to a compatible printer for direct printing of data or to a PC for data storage. It operates on a rechargeable NiMH battery pack or a 120V, 60Hz AC adapter/charger (both included). When operating on battery power, it automatically shuts down after 30 minutes of non-use to conserve battery life and has a low-battery indicator that signals when the battery needs recharging. It meets European Standard (EN) 61010-1:2001, American National Standards Institute and International Society of Automation (ANSI/ISA) S82.02.01, CAN/CSA (Canadian Standards Association) C22.2 61010-1-04, and UL (Underwriters Laboratories) 61010-1-04 safety standards, and is rated for CAT (category) III installations to 600V, which covers equipment in fixed installations, such as switches in the fixed installation and some industrial equipment that is permanently connected to the fixed installation. It has CE (European Conformity) marking. It comes with a 40MHz high-impedance voltage probe (with Fluke 124 models only), a set of test leads with mini clips and alligator clips, a BNC-to-banana adapter, a rechargeable NiMH battery pack (installed), an AC adapter/battery charger, and a user manual. The Fluke ScopeMeter 120 series is available with and without the SCC120 kit. The kit includes FlukeView CD-ROM software for storing and analyzing data, an RS-232/USB adapter cable for connecting to a PC, and a hard carrying case for storing the unit and its accessories. The software is compatible with Microsoft Windows 2000 and beyond operating systems. Specifications Display 2.83" monochrome LCD Bandwidths available 20MHz, 40MHz Input channels Two Real-time sample rate 25MS/s Record length 512 points per channel Maximum DC voltage measured 1,250V Maximum resistance measured 30M? Maximum capacitance measured 500?F Maximum frequency measured 50MHz for 20MHz bandwidth models, 70MHz for 40MHz bandwidth models Installation rating CAT III, 600V Standards met EN 61010-1:2001, ANSI/ISA S82.02.01, CAN/CSA C22.2 61010-1-04 and UL 61010-1-04 safety standards; CE marking H is height, the vertical distance from lowest to highest point; W is width, the horizontal distance from left to right; D is depth, the horizontal distance from front to back. Oscilloscopes are electrical testing devices used to verify the functionality of equipment that generates an electrical signal. Oscilloscopes measure the voltage of an electrical signal over time, and display the measurement as a waveform in a visual graph. The waveform shows the sweeps (or refresh) of voltage on a vertical (Y) axis, and the time on a horizontal (X) axis. Details of a waveform demonstrate the signal over time. Most oscilloscopes have two or four channels for inputting a signal. Some digital oscilloscopes offer more than four channels, allowing channels to be dedicated to specific signals and applications. Bandwidth is the maximum frequency of a signal that an oscilloscope can capture. A constant image will display if a signal is shown at a high frequency. Oscilloscopes may be analog, digital, or mixed signal. An analog oscilloscope directly displays an input signal as a continuous waveform, typically in a luminous phosphor on a cathode ray tube (CRT). A digital oscilloscope converts the input signal into a digital format and reassembles the waveform for display, typically on an LCD. A mixed signal oscilloscope (MSO) displays both analog and digital formats. Some oscilloscopes can display more than one channel and type of measurement simultaneously. Some oscilloscopes can capture waveform signals to memory, and recall them. They may provide real-time intensity grading, and may have the ability to adjust frequency of display. Oscilloscopes can be powered with batteries or electricity, or may have a built-in generator. They are commonly used for testing, measuring, and inspecting in science, engineering, telecommunications, automotive, and electronics applications. Fluke Corporation manufactures electrical testing tools and software for industrial and commercial applications. The company, founded in 1948, is headquartered in Everett, WA. What's in the Box? Fluke ScopeMeter series 120 handheld oscilloscope/multimeter 40MHz high-impedance voltage probe (with Fluke 124 models only) Set of test leads with mini clips and alligator clips BNC-to-banana adapter Rechargeable NiMH battery pack (installed) AC adapter/battery charger User manual SCC120 kit (for model with kit) FlukeView software RS-232/USB adapter Hard carrying case ADDITIONAL FEATURES Manufacturer: Fluke Corporation Shipping Weight: 1185 Product Dimensions: Width: 17.30 Length: 22.80 Height: 8.00 SHIPPING INFORMATION ● Our stock all ships from our US-based warehouses. ● Shipped via USPS or UPS or FedEx (depending on location and package weight) ● eBay Global Shipping Program - We are a part of eBay Global Shipping Program. This means that eBay will be responsible for shipping and import charges and times. We don't control the shipping times and import charges, which are based on your location in the world. You can find all the info in the eBay listing! RETURN & REFUND POLICY ● We offer a 30 day return/exchange policy for our products. ● You can choose refund or exchange if you are dissatisfied for any reason with your product. ● Only factory defects are accepted as a reason for a return. In the case of factory defects, we will replace the product for you. ● When returning an item, it must be in all of the original packaging and include all of the original accessories or items that came with it. The item and package should be in original and perfect condition. ● You will be required to cover shipping on the return of defective items. ● All returns MUST be done within 30 days of date of purchase. Please note that we cannot give refunds or replacements after the 30 day limit has expired. ● When sending in a return, please note that it can take up to 7 business days for the return to be processed. We do our best to process as quickly as possible. ● Buyers outside the U.S.A please note - ALL of our electrical appliances sold in our store are 110-120V. ● Return policy for buyers outside the U.S.A - We offer to return the items within 30 days. The BUYER will ship the item at his own cost. We are extremely fair, and in the rare event of something out of the ordinary happening with our products or shipping, we will gladly work with you to find a solution. ABOUT USA Daily Deals Since 2010 USA Daily Deals have been available to online customers, offering a variety of brand new products at great prices. All of our products ship directly from our different warehouses across the United States so you get your items quickly and in perfect condition. We know how important it is for you to get what you ordered and get it fast. Our products are a 100% authentic and brand new. We work with the biggest suppliers of high quality products to bring you only the best items. It is very important to us that we put our customers first and you will see this reflected in every transaction with us. We consider it a top priority that our customers are happy and in the rare event that they are not, we do everything we can to fix the situation. No customer will walk away from our store unhappy. If there?s a problem, just let us know and we fix it. We guarantee you only the best experience when shopping with us! Please see our other items Automotive Baby Camera & Photo Clothing Electronics Health & Personal Care Home & Kitchen Home Improvement Kitchen & Dining Office Products Shoes Sports & Outdoors Toys & Games Feedback Profile Other Auctions
