Fkm (viton) Sanitary Tri-clamp Gasket, White - 1.5"

US $2500

Wilmington, Delaware, United States
May 28th

Open on mobile:
QR code

A Division of Vertex Industries, Inc. Home About Us Contact Us Shipping & Returns Catalog Line Card Tech Info Clamps Compression Fittings Gaskets Hangers & Supports Hose Instrumentation Pipe Fittings Pipe Sight Glasses Steam Specialties Tools Tube Fittings Tubing Valves FKM (Viton) Sanitary Tri-Clamp Gasket, White - 1.5" Click images to enlarge. Specifications Description FKM Tri-Clamp® Gaskets are specified by many process equipment manufacturers and are generally suitable for these applications, however service life must be considered and a preventative maintenance program must be in place to mitigate degradation. While acceptable, we do not recommend FKM Gaskets for continuous use in SIP (steam in place) procedures. With that said, FKM Sanitary Gaskets have excellent compatibility with strong acids and maintain a broad range of operating temperatures from -30°F to 400°F. Storing FKM Gaskets: Shelf Life: 10 Years from cure date Store in original packaging in clean and dry warehouse Do not expose to direct sunlight Keep more than 6' away from electric motors Maintain temperature between 65°F and 85°F FKM Gasket Standards Compliance:FDA CFR 21, 177.2600 U.S. Pharmacopeia Class VI Certification USDA Hazard Analysis and Critical Control Points Cytotoxicity Criteria USDA and 3-A Sanitary Standards ASME-BPE Standards for Type I and Type II ADI Free® (Animal Derived Ingredient Free) Current Good Manufacturing Practices (CGMP) FKM Tri-Clamp® Gasket Features:Color Code: one white dot, one yellow dot • • -30°F to 400°F Temperature Range Acceptable for steam applications FKM Material is also available in:Type II Flanged Tri-Clamp® Gaskets Screen Gaskets Sock Gaskets Orifice Plate Gaskets Gauge Guards O-Rings Mini Steam Trap Orifice Plates ANSI 150# Flange Gasket ANSI 300# Flange Gasket Bevel Seat Gaskets I-Line Gaskets John Perry Gaskets Q-Line Gaskets DIN/ISO X-Ray Detectable Sheets Custom Gaskets, Profiles, Cord, Scrapers 1 = Excellent 2 = Good 3 = Acceptable 4 = Marginal 5 = Poor 6 = Do Not Use Cont. Steam Inter. Steam Pure Water Ambient Pure Water Hot Process Fluids Ambient Process Fluids Hot Process Fluid Variables 0°-100°C Temperature Range Tuf-Steel® 1 1 1 1 1 1 1 -350°-550°F Tuf-Flex® 1 1 1 1 1 1 1 -20°-300°F Food-Flex® 1 1 1 1 1 1 1 -30°-250°F PTFE 1 1 1 1 1 1 3 -100° to 500°F Silicone (platinum) 2 2 2 2 2 2 1 -40°-450°F Silicone (peroxide) 2 2 2 2 2 2 1 -40°-450°F FKM 3 2 2 2 2 2 2 -30°-400°F EPDM (peroxide) 3 3 3 3 3 3 3 -30°-300°F Buna 0 0 5 5 5 5 5 -30°-200°F Tri-Clamp® Gasket Sizing Size Inside Diameter Outer Diameter Bead Diameter 1/2" 0.40" (10.2mm) 0.87" (22mm) n/a 3/4" 0.64" (16.2mm) 0.87" (22mm) n/a 1" 0.90" (22.9mm) 2.00" (50.5mm) 1.71" (43.5mm) 1-1/2" 1.39" (35.3mm) 2.00" (50.5mm) 1.71" (43.5mm) 2" 1.88" (47.8mm) 2.52" (64mm) 2.22" (56.5mm) 2-1/2" 2.39" (60.5mm) 3.05" (77.5mm) 2.78" (70.5mm) 3" 2.88" (73.1mm) 3.58" (91mm) 3.29" (83.5mm) 4" 3.85" (97.7mm) 4.67" (119mm) 4.33" (110mm) 5" 4.86" (123.5mm) 5.68" (144.2mm) 5.29" (134.3mm) 6" 5.80" (147.2mm) 6.57" (167mm) 6.16" (156.5mm) 8" 7.80" (198mm) 8.56" (217.4mm) 8.15" (207mm) 10" 9.74" (247.4mm) 10.55" (268mm) 10.12" (257mm) 12" 11.74" (298.2mm) 12.56" (319mm) 12.17" (309mm) About Us Since 2002 Austenitex has been a value added distributor of process and industrial stainless steel pipe, tubing, components, and equipment. With a staff possessing many years of experience in engineering, design, construction, and maintenance, Austenitex has become a leader in the industry. We provide procurement and fulfillment services for one point of accountability. If you have special requirements, we can provide custom fabrication services. We can prepare submittal and turnover documentation to your specifications. We offer bagging and tagging services so that material is released to you by your drawing. Kitting, valve tagging, custom labeling, and special packaging services are also available. Our goal is to be a strategic partner to your operation. Our clientele appreciate the extra effort we expend to ensure they receive the correct product for their application, on time, at a competitive price. When you need it now and it has to be right, Austenitex is your solution! Shipping Terms We ship daily Monday - Friday and make every effort to ensure that your order is shipped the same or next business day of receiving your cleared payment. We reserve the right to combine shipments that are shipping to the same address. All of our products are shipped by either UPS or USPS with tracking information provided. The method displayed on this listing may be subject to change under certain circumstances. If you require expedited delivery services please contact us. International Orders We are happy to serve customers from all over the world. We gladly ship our eBay orders to Canada, Europe, Australia and New Zealand. Please contact us for a shipping quote. If you aren't in one of those countries, please contact us at (877) 304-3165. Please note that customs forms will be filled out as "merchandise" using your actual sale price as the value. We're not a great fan of customs taxes, but unfortunately it's illegal to try to avoid them. We hope you'll understand. Please contact your local post office or customs office to estimate potential customs charges to import our items from the USA. Feedback & Returns If anything at all is not as you had anticipated, please contact us, we are here to help! We will gladly leave positive feedback for our customers and we appreciate the same. If there is an error on our part, we will replace the goods at our expense. Please be sure to note your eBay Item ID number, eBay User Name and First and Last name in your email. Also save all original tags, packaging, and paperwork in preparation for return. Contact Us If you have a question, require special assistance, can't find what you are looking for, or would like to place a custom order please contact us by email or at (877) 304-3165. We are available from Monday - Friday 8AM - 5PM EST to assist you! We do our best to respond to emails within 1-2 business days. If you have a time sensitive matter, please call us.
