Exfo Ftb-1 Mainframe/ Fip400 Scope /bv10 /all Software Included.

US $64

Redmond, Washington, United States
Oct 20th

Open on mobile:
QR code

These are all recently calibrated and working. Included EXFO FTB-1-S1-8G Main Frame (BC# 22344) EXFO FTB-880 NetBlazer Multiservice Module w/ Options: (BC# 22345)DSn SONET 52M GigE Optical GigE Electrical Traffic Gen Champion 100SPF055 850 Transceiver Champion 100SFP10 1310 Transceiver (2) Ethernet Cables (2) BNC To BNC Cables SM LC-LC Duplex Fiber Cables MM LC-LC Duplex Fiber Cables Stylus AC Adapter/Charger Power Cord USB PC Interface Cable Strap For Unit BV10 Smart Loop back device Carrying Case (G) EXFO FTB-1 S1 - TFT Active Screen 8G - 8GB Internal Memory KEY FEATURES Flexible connectivity: USB, mobile, Wi-Fi and Bluetooth capabilities Utilities: supports third-party applications and all the tools that enable technicians to complete their work right in the field Test management/reporting: lets you take advantage of the EXFO Connect environment to monitor fi eld operations (local and remote) PC-oriented: Intel ATOM processor with Windows Embedded Standard operating system, for optimized productivity and versatility Power management: latest battery technology for unmatched operation autonomy MAXIMUM CONNECTIVITY FOR MAXIMUM FIELD-TESTING EFFICIENCY The result of EXFO’s time-proven expertise in portable platform design, the FTB-1 Platform is an open testing solution for network infrastructure construction and troubleshooting. The FTB-1’s built-in intelligence empowers frontline technicians to take field-testing efficiency to the next level. Thanks to a highly “connected” set of tools—including Update Manager and compatibility with the EXFO Connect environment, which provides end-to-end operational visibility and centralized reporting capabilities throughout the entire test instrument pool—the FTB-1 delivers maximum return on your investment. FEATURES USB, mobile, Wi-Fi and Bluetooth connectivity capabilities Supports third-party applications and all the tools that enable technicians to complete their work right in the field Lets you take advantage of the EXFO Connect environment to manage fi eld testing/reporting operations as well as your platform pool Intel ATOM processor with Windows Embedded Standard operating system, for optimized productivity and versatility Latest battery technology for unmatched operation autonomy One GigE port and two USB 2.0 ports Windows Remote Assistance and Remote Control EXFO fiber inspection probe connector interface Display: TFT outdoor-enhanced LCD, 7-inch touchscreen Telcordia-compliant THIRD-PARTY TEST TOOLS Wireshark This live-network packet capture utility makes it possible to look “inside” the packets and obtain data such as transmission time, source, destination, protocol type, etc. Users can then diagnose a problem or root out suspicious behavior. Wireshark is a standard utility on all FTB-1 platforms. JPerf This TCP performance testing tool can create TCP and UDP data streams which measure the throughput of a network that is carrying them. Thanks to various user-definable parameters, technicians can rely on JPerf to optimize or tune a network under test. Network Stumbler Network Stumbler verifies wireless network configurations, enabling field techicians to identify areas that have poor coverage or wireless interference, and helping them to aim antennas for full effect and find unauthorized access points. TECHNICAL SPECIFICATIONS Display Touchscreen, color, 800 x 480 TFT, 178 mm (7 in) Interfaces Two USB 2.0 ports RJ-45 LAN 10/100/1000 Mbit/s Fiber inspection probe connector port (video) Storage 8 GB internal memory (flash) Batteries Rechargeable lithium-ion batteries 8 hours of operation as per Telcordia* (Bellcore) TR-NWT-001138 Power supply AC/DC adapter, input 100-240 VAC, 50-60 Hz, 2 A max, output 24 VDC, 90 W Computer Intel ATOM processor Windows Embedded Standard operating system GENERAL SPECIFICATIONS Size (H x W x D) 190 mm x 252 mm x 66 mm (7 1/2 in x 9 15/16 in x 2 5/8 in) Weight (with battery) 1.5 kg (3.3 lb) Temperature Operating 0 °C to 50 °C (32 °F to 122 °F) Storage –40 °C to 70 °C (–40 °F to 158 °F)(Without Battery) Relative humidity 0 % to 95 % non-condensing PM-1 BUILT-IN POWER METER SPECIFICATIONS Calibrated wavelengths (nm) 850, 1300, 1310, 1490, 1550, 1625, 1650 Power range (dBm) 10 to —86 (InGaAs) Uncertainty (%) b ±5 % ± 3 pW (InGaAs) Display resolution (dB) InGaAs 0.01 = max to —76 dBm 0.1 = —76 dBm to —86 dBm 1 = —86 dBm to min Automatic offset nulling range Max power to —63 dBm for InGaAs Tone detection (Hz) 270/1000/2000 VISUAL FAULT LOCATOR (VFL) Laser, 650 nm ± 10 nm CW Typical Pout in 62.5/125 µm: 3 dBm (2 mW) FTB-880 NetBlazer Multiservice Housed in the FTB-1 Platform, the FTB-880 offers comprehensive, yet simple test suites for field technicians to easily turn up, validate and troubleshoot DSn/PDH, ISDN, SONET/SDH, OTN, CPRI/OBSAI and SyncE/1588 PTP services . Key Features Comprehensive testing for DSn/PDH, ISDN, SONET/SDH, OTN and Ethernet interfaces. Efficiently assess Fibre Channel networks with best-in-class coverage via 1x, 2x, 4x, 8x and 10x interfaces Packet synchronization turn-up and troubleshooting (SyncE/1588 PTP) FTTA validation (CPRI and OBSAI) at up to 3.1 Gbit/s via BER testing Complete ISDN solution for testing and troubleshooting DS1 or E1 primary rate interfaces (PRI) Simplified BER testing with pass/fail indicators based on user-defined thresholds OTN testing (as per ITU-T G.709) including forward error correction (FEC) Faster Ethernet service activation with bidirectional EtherSAM (ITU-T Y.1564) and RFC 2544 test suites, multistream traffic generation, Through mode and bit-error-rate (BER) testing Unprecedented configuration simplicity with hybrid touchscreen/keypad navigation and data entry Increase technician autonomy and productivity with intelligent discovery of remote EXFO Ethernet testers, as well as in-service Ethernet testing via dual-port Through mode No data interpretation errors with revolutionary new GUI on 7-inch TFT screen, historical event logger, visual gauges and 3D-icon depictions of pass/fail outcomes Simpler reporting with integrated Wi-Fi and Bluetooth connectivity capabilities Centralized support for injection/monitoring of errors and alarms, trace messaging, overhead monitoring/manipulation and performance monitoring statistics Integrated applications to test VoIP services, and additional IP test utilities, including VLAN scan and LAN discovery via EXpert VoIP and EXpert IP test tools Support for packet capture and analysis, wireless troubleshooting and TCP throughput testing Gigabit Ethernet Tester: The Ultra-Portable Choice for Multiservice Testing The ongoing transition towards a converged network infrastructure for legacy DSn/PDH, ISDN, SONET/SDH, OTN, Fibre Channel and packet-based Ethernet services requires a test tool that can cover a wide range of interfaces and rates, without sacrificing portability, speed or cost. Leveraging the powerful, intelligent FTB-1 handheld platform, the FTB-880 NetBlazer streamlines processes and empowers field technicians to test and validate DSn/PDH, ISDN, SONET/SDH, OTN, Fibre Channel and Ethernet circuits efficiently. Powerful and Fast The FTB-880 NetBlazer is a fully integrated DSn/PDH, ISDN, SONET/SDH, OTN, Fibre Channel and Ethernet handheld tester. It offers the industry's largest touchscreen with unprecedented configuration simplicity via hybrid touchscreen/keypad navigation. Platform connectivity is abundant via Wi-Fi, Bluetooth, Gigabit Ethernet or USB ports, making it accessible in any environment. What You Need for Any DSn/PDH, ISDN, SONET/SDH, OTN, Fibre Channel or Ethernet Application Installation, commissioning and maintenance of access and metro networks Turn-up of DSn/PDH, ISDN or SONET/SDH circuits Performance assessment of Carrier Ethernet services Validation of OTN networks and services Installation, activation and maintenance of metro Ethernet networks Deployment of active Ethernet (point-to-point) access services Installation and activation of Fibre Channel networks Testing and troubleshooting In-service troubleshooting of live traffic Performance monitoring of DSn/PDH, ISDN, SONET/SDH and OTN circuits Round-trip delay assessment of transport circuits FTTA validation (CPRI and OBSAI) at up to 3.1 Gbit/s via BER testing DSn/PDH, ISDN, SONET/SDH, OTN, Fibre Channel and Ethernet If the need is for multiservice testing, then the FTB-880 is the perfect solution.
