ESR Meter Digital SMD/DIP Transistor Tester Diode Triode Capacitance MOS PNP NPN dww Description Function: 1. Automatic recognition transistor type, pin, current magnification and the base - emitter junctionvoltage measured at the same time. 2. Automatic Identification of N and P MOSFET type and pin,measure the voltage and capacitance. 3. Automatic identification the diode pin, measurement the forward voltage. 4. Automatic identification of small power triac pin. 5. Measuring resistance. 6. Measuring inductance.Inductance measuring range: 0.01mH~20H,R≤2100Ω 7. Measuring Capacitance. Features: Can measure the various diodes , transistors , MOS FET ; able to determine the device type , the polarity of the pins given HFE, the threshold voltage, the FET junction capacitance, can be measured capacitance and resistance, etc. Pin can be connect random,Screen gives corresponding test No of the pin Input voltage :9v Before Measuring capacitance , Must discharge fully, or will destory the tester 1. 2013 latest M168 version of the software ,more functions. 2. Use 8MHz external crystal , better measurement accuracy. 3. Backlight LCD display,only 2mA when stand by. 4. Using 9V battery. Specifications: 1. One -button operation, automatic shutdown . 2. Only 20nA shutdown current. 3. Automatically detect NPN, PNP bipolar transistors , N -channel and P -channel MOS FET, JFET , diodes , two diodes, thyristors small power unidirectional and bidirectional thyristor. 4. Automatic identification components pin arrangement . 5. Measuring bipolar transistor current amplification factor and base - emitter threshold voltage. 6. Via the base - emitter threshold voltage and high current amplification factor to identify Darlington transistors. 7. Can detect bipolar transistors and MOS transistors protection diodes. 8. Measuring the gate MOS FET threshold voltage and the gate capacitance. 9. Can simultaneously measure two resistors and resistor symbol is displayed. Displayed on the right with a decimal value of 4 . Resistance symbol on both sides shows the pin number. So you can measure the potentiometer. If the potentiometer wiper is not transferred to an extreme position , we can distinguish the middle and both ends of the pin. 10. Resistance measurement resolution is 0.1 ohms , 50M ohms can be measured . 11. Can measure capacitanceCan measure capacitance of 30pF-100mF , resolution 1pF. 12. 2uF more capacitors can simultaneously measure the equivalent series resistance ESR values. The two can be displayed with a decimal value , resolution 0.01 ohms. 13. Can be in the correct order and the diode symbol display two diodes , and gives the diode forward voltage. 14. LED is detected as a diode forward voltage higher . Combo of the LED is identified as two diodes. 15. Eeverse breakdown voltage is less than 4.5V Zener diode can be identified. 16. Can measure a single diode reverse capacitance. If the bipolar transistor connected to the base and collector or emitter of a pin , it can measure the collector or emitter junction reverse capacitance . 17. can be obtained with a single measurement rectifier bridge connection. Notice: Before measuring capacitance , the capacitor must be discharged , otherwise very likely damage the meter . Package Includes: 1 x New Transistor Tester Capacitor ESR Inductance Resistor LCR Meter Payment We only accept payment through Paypal. Please pay for your item within 4 days of the auction end time. A non-payment dispute will be regrettably opened if full payment is not received. Delivery details We ship worldwide except Italy and Brazil due to their strict customs tariff policys. All items will be shipped to buyer's ebay address. Before you pay, please make sure your address in ebay matches the address you would like us to ship to. (If you want to change the address, pls. add a note when you make the payment) Any non-received items caused by invalid address registered on PayPal are not in our full refund or replacement policy. A notification email of dispatch will be sent to buyer after item is posted. Please email us if you don't receive our email after 5 days of full payment sent. All items will be shipped within 48 hours upon receipt of payment. You should be able to receive items within 3 weeks. Email us if not receive items after 30 working after full payment sent. Return Policy We have done our best to accurately and faithfully describe this item and are committed to ensuring your satisfaction with your purchase. If you receive an item that is not accurately described, please contact us within 45 days of receipt and prior to leaving feedback. We will issue a refund upon our receipt of the original product which must also be in original condition. Buyer is responsible for shipping costs incurred when shipping products back.If we are in error (Defective Product or Shipped Wrong Item), we will gladly ship you a new item. We will do our absolute best to work out a solution to your satisfaction! About us We are a professional trading company specializing in video games, car accessories, spy equipments and other electronic products. We will always do our up most to exceed your expectations in customer service, communication and dispatching of your orders. If you want to do wholesale business with us, pls. feel free to contact us for discounts. Any questions pls. contact us via ebay message or email us. It's in our interest to answer questions quickly and give good prompt service. We will reply your message within 48 hours. If you do not receive our reply within 48 hours, pls. post the message again because sometimes the email may be blocked by the message system. feedback If you are satisfied with our service, pls. kindly leave us a positive feedback and give us the Detailed Seller Rating with all "5 stars" in very area. Your recognition will encourage us greatly and serve you better. Should a problem arise with your order, please contact us before leaving feedback. We strive to keep all our customers satisfy. Thanks! Your feedback is critical to our success! Engineered for professional eBay sellers! On 22-Sep-14 at 03:55:40 EDT, seller added the following information:
