Electro Switch Rotary Military Surplus Series 21 21204a Dustproof New

US $49

  • Westerville, Ohio, United States
  • May 27th
FOR SALE IS A BRAND NEW ELECTROSWITCH ROTARY SWITCH. THIS MILITARY SURPLUS ITEM HAS A PART NUMBER OF 21204A AND AN NSN OF 5930001061437. THE SPECIFICATIONS ARE AS FOLLOWS:  MRC Parameter Characteristics AAJD Thread Class 2B single mounting facility ABFE Hazardous Locations/Environmental Protection Dustproof ABHP Overall Length 4.313 inches nominal ABKW Overall Height 2.812 inches nominal ABMK Overall Width 2.812 inches nominal ABXF Shaft Length 1.125 inches nominal single actuator AFBH Individual Section Quantity 4 AFCQ Knob Manufacturer Code Electro Switch Corp. (82121) AFCY Knob Manufacturer Part Number A AFDS Longest Horizontal Distance Between Mounting Centers 2.297 inches nominal single mounting facility AFDV Longest Vertical Distance Between Mounting Centers 2.297 inches nominal single mounting facility AJZE Switch Contact Basic Design Nonpile-up symmetrical AKPX Pole Quantity 2 each section rear AKPY Throw Quantity 3 each section rear AXGY Mounting Method Bracket single mounting facility and threaded hole single mounting facility CBBL Features Provided Actuator knob CMLP Thread Quantity per Inch 24 single mounting facility CQJX Nominal Thread Size 0.190 inches single mounting facility CQMK Contact Voltage Rating in Volts 125.0 highest dc voltage rating at sea level CQMK Contact Voltage Rating in Volts 125.0 lowest ac voltage rating at sea level CQMK Contact Voltage Rating in Volts 240.0 highest ac voltage rating at sea level CQMK Contact Voltage Rating in Volts 28.0 lowest dc voltage rating at sea level CQYJ Mounting Facility Pattern Four position rectangular single mounting facility CRJH Switch Actuator Indexing Position Quantity 3 single actuator CRSJ Shaft Type Rectangular/square, threaded hole single actuator CRTY Square Shaft Size 0.250 inches nominal single actuator CSCF Terminal Type Tab W/screw CSHW Contact Switching Action Breaks before makes each section rear CSLC Switch Actuator Positioning Increment 45.0 degrees single actuator CTDN Switch Actuator Stop Device Type Adjustable stop single actuator CTHF Contact Load Current Rating 2.0 amperes resistive load highest dc voltage rating at sea level CTHF Contact Load Current Rating 10.0 amperes resistive load lowest ac voltage rating at sea level CTHF Contact Load Current Rating 10.0 amperes resistive load lowest dc voltage rating at sea level CTHF Contact Load Current Rating 5.0 amperes resistive load highest ac voltage rating at sea level STYL Style Designator Tap, circuit selector THSD Thread Series Designator Unc single mounting facility IF YOU HAVE ANY QUESTIONS, PLEASE FEEL FREE TO CALL ME 1-614-580-0951. You will not be disappointed. My feedback speaks for itself. If you have any questions please email me and check out the other items I have for sale. If you have problems with your order, PLEASE CONTACT ME BEFORE LEAVING FEEDBACK. Thanks, Mark ATTENTION! – ATTENTION! – NOTICE! – NOTICE! BEFORE LEAVING FEEDBACK PLEASE CONTACT ME. I WANT TO MAKE YOU HAPPY AND FIX THE ISSUE. IF YOU BOUGHT THE WRONG THING, IT IS BROKEN, IF SHIPPING TOOK TOO LONG OR EVEN IF YOU’RE HAVING A BAD DAY. I WANT TO HELP!! I WANT TO KEEP MY FEEDBACK CLEAN.
