Elatec Ceramvac Vii Vacuum Furnace 2200 C, Graphite Chamber 24"w X 36"l X 18"h

US $8000

Tolland, Connecticut, United States
May 24th

Open on mobile:
QR code

Elatec Vacuum Furnace. Used. In Storage in a climate controlled warehouse. Ready to Ship. Call us with any questions, or for more information, or to schedule an inspection! 860-875-3712 Item #: 3569 Brand: Elatec Technology Corp. Model: CERAMVAC VII Job No.: 575 Voltage: 460 Phase: 3 Hz.: 60 KVA: 270 (Total of VRT's) Heated Zone: 18"W x 36"L x 18"H @ 1550 C / 2822 F Max. Temp.: 2200C / 4000 F (Graphite Liner with Graphite elements) Year Mfg.: Prints Dated 1989 - 1990 Chamber Size I.D.: 24"W x 36"L x 18"H (above hearth) Assembled O.D.: 138"L x 186"W x 143"H (according to layout drawing allowing for space between components) Assembled Weight: Estimated. 20,000 Lbs. Mechanical Pump: Stokes 412 (300 CFM) 7.5 HP per prints Booster Pump: Roots 612. 2 HP per prints Diffusion Pump: 20" Varian. 12 KW per prints VRT's: (6) HUNTERDON SPEC #ELA-1015-1, 45 KVA, 460 VOLTS PRIM, 33 VOLT SEC. DC CONT. 3.5 VOLTS, 40 AMPS There are crates containing some interconnection piping. It is not known if all piping components are present. Controls: Honeywell DCP700 digital indicating program controller, Honeywell UDC digital indicating over-temperature control, Granville Phillips 307 Vacuum Gauge Control, and PLC Allen Bradley SLC150 with (2) SLC100 expansion controls mounted in an enclosed free standing panel. General: Stainless steel Double wall, horizontal load, water cooled chamber with side swing doors front and back. Interior has graphite liner with graphite heating elements. Designed for heated zone of 18"W x 36"L x 18"H @ 1550 C / 2822 F. Maximum temperature is rated 2200 C / 4000 F according to literature. Requires 45 GPM cooling water, 70 F and 35-40 PSIG at inlet. Inert gas feed of dry nitrogen or equivalent for inert atmosphere and/or cooling/backfill. Compressed air, filtered and lubricated, 90 PSIG. Actual operational condition is unknown. There are exterior cosmetic issues such as dust, and small paint scratches/scuffs. Vessel appears to be in great condition with NO hot spots, dents, or cracks. Pumping system has very small amount grease and oil stains. All elements and element holders, connections, and terminals appear to be in good condition. The work load graphite box is a (6) piece constructed box held together with graphite screws. Some graphite screws have sheared off allowing the box to lean. The back wall of the graphite box has a chipped corner. The box will either need to be repaired or replaced. Graphite box will be removed and packaged separately prior to shipping. Graphite hot zone surround appears to be complete and in good condition. There is some visible wear around the hot zone door opening. There are over a dozen spare elements that appear to be unused. Prints and manuals appear to be complete, but completeness cannot be verified. Sold AS-IS. Electrical and layout prints, parts lists, and manuals will be shipped with the furnace. Please call if you would like to see prints and manuals. This furnace is sold “AS IS” with a 30 day return privilege. Buyer pays all shipping costs. Buyer may pick up this item. This item may be for sale locally. Seller has the option to end the listing prior to the scheduled end date. Inspections are invited and suggested. Item located at: Tolland, Connecticut 06084 Phone: 1-860-875-3712 Payment: We accept Company Check, or bank wire transfer. Item usually ships 1-2 days after payment has been received full and clear. International shipments require broker and additional information for customs. Shipping: This item can be shipped via step deck trailer, or you can pick it up with proper equipment. Please call us for a shipping quote before bidding. Furnace Brokers, Inc. 860-875-3712 Please visit www.FURNACEBROKERS.com to see our full inventory.
