Dwyer Visi-float Series Vfa Flowmeter, 2" Scale, Range 0.06-0.5 Lpm Air, With

US $1600

  • USA, United States
  • Jun 22nd
Home page About Us Feedback See our other products Add to Favourite Contact us Shop categories Baby Automotive Electronics Home Improvement Kitchen & Dining Home & Kitchen Musical Instruments Office Products Toys & Games Shop pages Home page See Our Other Products Add to Favourite About the seller Dwyer Visi-Float Series VFA Flowmeter, 2" Scale, Range 0.06-0.5 LPM Air, with Stainless Steel Valve, 1/8" Female NPT Process Connection Product Specification 2" scale flowmeter with 1/8" female NPT connections for inline monitoring and measuring air flow Accuracy of + or - 5% of full scale Precision machined from solid acrylic plastic to resist breakage and provide a clear view of the scale Black scale graduations are hot-stamped into the plastic for distinct readings Lightweight flowmeter has a metal mounting insert for panel mounting and can also be supported directly by system piping Features The Dwyer Visi-Float series VFA flowmeter is a 2" scale air flow meter with 1/8" female NPT inlet and outlet connections for inline monitoring and measuring of air flow with an accuracy of + or ? 5% of full scale, and is precision machined from solid acrylic plastic to resist breakage and provide a clear view of the scale. Black scale graduations are hot-stamped into the plastic for distinct readings. This lightweight flowmeter has a metal mounting insert for panel mounting and can also be supported directly by system piping. Models are available for measuring air flow in scfh or lpm. Some models come with a brass or stainless steel metering valve for precise adjustment of air flow. Inlet and outlet connections are brass except for models with stainless steel wetted parts and the connections are on the back of the flowmeter except for models that have end connections. This flowmeter is commonly used for measuring air flow in medical equipment, air samplers, gas analyzers, pollution monitors, chemical injectors, and cabinet purging equipment, among other devices. Specifications Scale length 2" (on average) Accuracy + or ? 5% of full scale Connections 1/8" female NPT inlet and outlet Pressure and temperature rating Without valve: 100 psig/6.9 bar @ 65 degrees C/150 degrees F; with valve: 100 psig/6.9 bar @ 48 degrees C/120 degrees F Wetted materials Body: acrylic plastic; O-ring: Buna-N; metal parts: brass (standard) or stainless steel (applicable models); float (varies by range): black glass, nickel/copper alloy, stainless steel, or aluminum Dimensions (H x W x D) 104.0 x 25.40 x 31.75 mm/4-3/32 x 1 x 1-1/4 inches Weight 0.11 to 0.14 kg/4.0 to 4.8 oz. H is height, the vertical distance from the lowest to highest point; W is width, the horizontal distance from left to right; D is depth, the horizontal distance from front to back. Anemometers, also called wind meters, measure air velocity and are most commonly used for weather monitoring to determine wind speed and for HVAC applications to determine air flow within ducts. In addition to air velocity, anemometers may measure wind direction, air pressure, air flow volume, air temperature, humidity, light, and other properties. The most common types of anemometer are cup, vane, hot-wire, and Pitot tube. Cup and vane anemometers calculate air velocity based on the number of rotations of the cups or vane. Hot-wire anemometers calculate air velocity by measuring the change in electrical resistance as air flow cools a heated wire. Pitot tube anemometers measure air pressure within a tube and calculate air velocity based on the difference in pressure between the air inside and outside of the tube. Many anemometers have digital readouts and can display air velocity readings in different units of measure, such as meters per second (m/s), feet per minute (ft./min. or fpm), knots, miles per hour (mph), and kilometers per hour (km/h). Dwyer Instruments manufactures measurement and control instruments, including pressure gauges, flow meters, level instrumentation, temperature instrumentation, and air quality monitors. The company, founded in 1931, is headquartered in Michigan City, IN. Additional Information Manufacturer: Dwyer Instruments Shipping Weight: 30 Product Dimensions: Width: 2.20 Length: 4.30 Height: 1.10 Delivery Information Refunds & Returns About Us Our Guarantee Contact Us All our stock is at our US warehouse.Your item will be shipped by either DHL or UPS depending on the size/weight of the package and delivery location. We aim to ship orders within 24hours of processing your payment. Shipping is free. 30 day return or exchange policy for all our products. Only factory defects are accepted as the reason for product return. Returned item(s) must be returned with package completely intact, and all accessory(s) inside the package must be original condition.We do not pay for the postage costs for returned defective items.Items returned must be received within 30 days from purchase. No refund or replacement is issued after 30 day time period after purchase. Please allow up to 7 working days to process your returned item(s) after we receive it.We are extremely fair, and in the rare event of something unusual happening, we will gladly work with you to find a solution. We sell on eBay since 2007. We are based in the US and ship from our own warehouses. Our products are 100% authentic and all brand new. We work with the biggest suppliers in the UK to bring you the best quality items!We guarantee to provide the best service. Customer satisfaction guaranteed!We offer a 100% Satisfaction Guarantee on all sales. If you are not happy with your purchase for any reason, please contact us within seven days of receipt of your item, or email us to share your concerns. We are extremely fair and will happily work with you to find a solution to any problem.We aim to maintain 100% feedback, and we want every single one of our customers to be a happy one. So in the rare case something does go wrong, before leaving a negative feedback, contact us so we can help make things right! In the rare event that you have an issue with your product or our service please contact us by email to share your concerns, we will respond within 24 hours to help to rectify the problem.
