Dual H Bridge DC Stepper Motor Drive Controller Board Module L298N for arduino Description Basic Attributes Name Double H Bridge Motor Driver Module Working mode Drived by H bridge (double lines) Control chip L298N ( ST ) Logical voltage 5V Driving voltage 5V — 35V Logical current 0mA-36mA Driving current 2A (MAX single bridge) Storage temperature ( -20 ℃)—( +135 ℃) Maximum power 25W weight 30g Periphery dimension 43*43*27mm Product features: 1.Using L298N made by ST company as the control chip,the module has such characteristics as strong driving ability,low calorific value and strong anti-interference ability. 2.This module can use built-in 78M05 for electric work via a driving power supply part.But to avoid the damage of the voltage stabilizing chip,please use an external 5V logic supply when using more than 12V driving voltage. 3.Using large capacity filter capacitor,this module can follow current to protect diodes,and improve the reliability L298N is a kind of high voltage,high current motor driver chip produced by ST company.Having 15 pins as package, this chip has such features as high working voltage(maximum voltage up to 46V),large output current(instantaneous peak current up to 3A,continuous working current 2A) and 25W of rated power.Two built-in H birdge high voltage and large current full bridge drivers can be used to drive the DC motor and stepper motor,relay coil and so on.Using standard logic level signal control,it has two enable control ends.It permits or prohibites device having a logic power supply imput without the impact of input signal,which enables the internal logic circuit part works at low voltage.The chip can connects to external detecting resistor to give the variations to the control circuit.Using L298N chip to drive the motor,this chip can drive a stepping motor or four phase stepping motor,and two DC motors as well. This module is integrated with a built-in 5V power.When the drive voltage is 7V-35V, it can enable the onboard 5V logic power supply;afterthe power supply,don't input voltage in the interface+5V power supply,but you can lead the 5V for external use. when ENA enable IN1 IN2 control OUT1 OUT2 when ENB enable IN3 IN4 control OUT3 OUT4 Applied cases: 1 Driving stepper motor The connection of driving a common 4 line 2 phase electric motor is shown in below figure after enable ENA ENB Input the following driving timing from IN1-IN4,then the speed and direction of the stepper motor can be controlled Payment 1. We accept payment via PAYPAL ONLY. 2. Payment must be made within 4~7 days of auction closing. 3. TOTAL AMOUNT DUE includes the final auction price plus S&H(Shipping and Handling) 4. S&H will be determined based upon the SHIP TO address. PLEASE NOTE: S&H DOES NOT INCLUDE DUTIES, LOCATL TAXES OR ANY OTHER IMPORTATION FEES. 5. Please list your special requests (color, packages, etc.) in the PAYPAL NOTES SECTION when you make payment. Delivery details 1. Items are dispatched within 48hours(except weekends and holidays) 2. Local pick up is not available. 3. Customers in Porto Rico, Alaska and Hawaii are recommended to contactus for shipping details(shipping cost&time) before placing an order. Warranty Returns&Refunds Return: 1.This product comes with 30-Day Money Back Guarantee. 2.If you receive an item and it doesn't work properly or you don't likeit because of any reason at all, we have a 100% refund/return policy. Wewill ship you a new item or refund your money for the full sale amount. 3.For all returned products, buyers MUST contact us for the returningaddress. Warranty: 1.Warranty will be valid for 12 months against manufacturing defect. 2.The warranty shall not apply to the following circumstances Feedback Please email us before leaving negative and neutral feedback. We will try ourbest to solve the issue. Your satisfaction is our first priority. We appreciateyour positive feedback. Contact us 1.We have alwaysbeen trying to provide the best service and reliable products for every customer, however, accident may happen sometimes, please contact us toresolve any issue before leaving a negative feedback. 2. We will reply you ASAP. If no response within 24 Hours, please check the spam in your mail box. Engineered for professional eBay sellers! On Dec-30-14 at 17:27:46 PST, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Type	Electronic Components
Maximum power	25W
Brand	ABK
Periphery dimension	434327mm
Model	L293N
Logical voltage	5V
MPN	L293N
Logical current	0mA-36mA
Country/Region of Manufacture	China
Storage temperature	( -20 °C)—( +135 °C)
Driving voltage	5V — 35V
Working mode	Drived by H bridge (double lines)
Driving current	2A (MAX single bridge)
