Dso Nano V3 Digital Storage Oscilloscope By Seeedstudio Ships From Usa

US $94.50

  • Stoneham, Massachusetts, United States
  • Mar 27th
  SeeedStudio SKU TOL01241P DSO Nano V3 Oscilloscope LATEST VERSION!!!Ships free from Stoneham, MA USA DESCRIPTION The DSO Nano V3 is a pocket-size compatible 32bit digital storage oscilloscope. Based on ARM -M3, it’s equipped with 320*240 color display, SD card, USB port and recharging function. It’s compact, simple to operate; meets the basic demands of school lab, electric furniture repairment and electric engineering.   This is a updated and cool version of DSO Nano which features a firmware and a embedded 2 Mbyte storage chip instead of micro SD card slot. The documents of this version in detail is on this page, please refer to it.    Updates in v3: V3 used a new firmware with user-friendly interface, easier to operate Upgraded firmware via virtual disk Added build-in 2Mbyte storage chip instead of micro SD card slot Black metal shell   Features Portable and lightweight Color display Waveform storage and playback 6 triggering modes 200Khz Analog Bandwidth Complete measurement markers and signal characteristics Built-in Signal Generator Accessories available Open Source   Specifications Display: 2.8’’ color TFT LCD Display Resolution: 320x240 Display Colors 65K Analog Broadband: 0 ~ 200kHz Max. Sampling Rate: 1Msps 12 bit  Sampling Storage Depth: 4096 points  Transverse Sensitivity: 1uS/Div~10S/Div(1-2-5 stepping)  Vertical Sensitivity: 10mv/Div~10V/Div(x1 probe) 0.5V/Div~10V/Div(x10 probe) Input Resistance: >500K? Max. Input Voltage: 80Vpp(x1 probe)400Vpp(x10 probe) Coupling Mode: DC Triggering Mode: Auto,Normal,Single,None Auto Measurement: Frequency, cycle, duty, Vpp, Vram, Vavg, DC voltage; Vertical Precise Measurement Cursor; Horizontal Precise Measurement Cursor; Rising/Falling Edge Trigger; Triggering Cursor; Triggering Sensitivity Cursor; Hold/Run Inbuilt Test Signal: 10Hz~1MHz(1-2-5 stepping)  Waveform Storage: build-in 2Mbyte PC Connection Interface: Connection through USB Recharging Method: Recharging through USB interface  Dimensions:105mm x 53mm x 8mm   Documents User’s Manual Schematic Design Firmware   Shipping * FAST USPS SHIPPING! (only to addresses that are deliverable via USPS) * Orders placed by 2 pm EST MON-FRID  are shipped the same day! * Time in transit cannot be guaranteed but is typically 2-5 business days depending on your location. * Items are shipping from Stoneham, MA Payment * Payment is only accepted through Paypal. * Must ship to a confirmed address, otherwise payment will be refunded and I will alert you to the cancellation. * Immediate Payment is required. Terms * Returns are accepted only if the package has not been opened or damaged and the item is returned before 14 days or delivery.  * Buyer pays return shipping. Feedback I strive to offer the best customer service possible and earning top feedback and star ratings. Please contact me with any issues before leaving feedback and I will do everything possible to assure the optimal outcome. Thank you for your business!
This is a brand new oscilloscope, never used. We had to open one box to show the customs officer the contents of our shipment. we ordered 30 units for our online store.it comes with all accessories shown all still sealed.
Brand SeeedStudio
MPN TOL01241P
Model TOL01241P
Type Digital
