Diy Kit Capacitance Esr Inductance Resistor Lc Meter Tester Npn Pnp Mosfet M168

US $14.45

Shenzhen, China
Jan 29th

Open on mobile:
QR code

DIY Kits Capacitance ESR Inductance Resistor LC Meter Tester Overview: It is DIY Kits, has not soldered, Atmega168 has been programmed, without battery. Specification: Measurement Range: Resistor: 0.5 ?-50M? Capacitor: 30pF-100mF Inductance: 0.01MH-10H Working voltage: 6FF22 9V Battery or DC 5.5-12V via DC socket. Controller: ATmega168 Standby current: 0.02uA Operating current: 25mA Features: l One key measurement operation, the time delay automatically shut off the power. Shut off the current 20 na, support for battery operation. l Automatic detection of PNP and NPN bipolar transistor, N, P channel MOSFET, jfets field-effect tube, diode, double diode, thyristor, resistance, capacitance and inductance. Automatically detect pin definition. l Measure the bipolar transistor current amplification coefficient (B) and emission of conduction voltage (Uf). Darlington transistors can be high threshold voltage and high current amplification factor recognition. l Can detect the bipolar transistor and the inside of the MOSFET protection diode and display on the screen. l Measure the MOSFET threshold voltage and gate capacitance value. l Support two resistance measurements, potentiometer can also be measured. If one end of the potentiometer to adjust to it, the tester is unable to distinguish between the middle and at the ends of the pin. l The resolution of the resistance measurement is 0.1 ohms, highest measured value up to 50 m ohm. l Pf capacitance measurement range from 25 to 100 mf (UF) 100000. Resolution can reach 1 pF. l Can detect more than 2 uf capacitor equivalent series resistance (ESR), a resolution of 0.01 ohms. This function for detection capacitance performance is very important. l Two diodes can be displayed in the right direction signs, also showed a positive pressure drop. l LED detection for diode, positive pressure drop than normal on the high side. Double light emitting diode detection for the diode. Detection of leds will shine. l Each test time is about two seconds, only large capacitance and inductance measurement will need a long time. Package include: 1 * DIY Kits Capacitance ESR Inductance Resistor LC Meter Tester(need soldered, not include battery) Shipping l Before you pay, please make sure your address matches the address you would like us to ship to. l After full payment is received and cleared, your item will be shipped ASAP. Generally, delivery time is 20-40 days. l Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Please check with your country's customs office to determine what these additional costs will be prior to bidding/buying. Return Policy l We are committed to give you the best customer service possible. If for any reason you are dissatisfied with a purchase, please contact us and we'll assist you with a prompt solution. We'd like to settle any problem in a friendly manner. l We want to make sure you are happy with our item. If for any reason you wish to return the item, contact us within 14 days from the delivery date and we will give you a full refund or exchange. Only unused, undamaged and original condition item can be qualified for a return. Buyer is responsible for return shipping fee. Please contact us to get a RMA number BEFORE sending out your return. Goods without RMA number will NOT be accepted. Please write the RMA number on the returning package. l We will not be liable to customer for any damages beyond the amount of money that customer has actually paid us. Contact us l We care about our valued buyers, please contact us through email with any questions or concerns. We will reply to messages within 2 business days. Emails, which are received during the weekend, will be replied on Monday. If you do not received a response in expected time period from us, please check your junk or spam mailbox. l Our goal is to make sure you are a happy buyer and have a pleasant shopping with us. If you are happy with our item and service, please do leave us positive feedback and 5 star rate. Please email us before leaving any 1 or 2 ratings, neutral or negative feedback or open any dispute. We understand the concerns and frustrations you might have, and will do our endeavor to resolve the issues. Please give us the opportunity to resolve any problem. l Thank you for your effort to make this sale and purchase experience a happy one!
