Digital True Rms Inrush Current Clamp Meter 6kcounts Dc Ac V/a Ohm Cap Freq. Ncv

US $66.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

MS2115A The AC digital clamp meter is an autorange professional clamp meter with 6000 counts. For measuring DC and AC voltage, DC and AC current, Resistance, Capacitance, Frequency with TRMS function. Specification Range Accuracy MS2115A MS2115B DC Voltage 60mV/600mV/6V/60V/600V +-(0.7% +3) 600mV/6.6V/66V/660V +-(0.5% +3) 1000V +-(0.8% +2) +-(0.8% +2) AC Voltage 60mV/600mV/6V/60V/600V +-(0.8% +3) 600mV/6.6V/66V/660V +-(0.8% +3) 750V +-(1% +4) +-(1% +4) DC Current 60A/600A/1000A +-(2.5% +6) 66A/660A/1000A +-3.0% +3) AC Current 60A/600A/1000A +-(2.5% +6) 66A/660A/1000A +-(2.5% +3) Resistance 600ohm/6kohm/60kohm/600kohm/6Mohm +-(0.8% +3) 60Mohm +-(1.2% +3) 660ohm/6.6kohm/66kohm/660kohm/6.6Mohm +-(1.0% +3) 66Mohm +-(1.5% +3) Capacitance 10nF/100nF/1000nF/10uF/100uF/1000uF/10mF/100mF +-(4.0% +5) 6.6nF/66nF/660nF/6.6µF/66µF/660µF/6.6mF/66mF +-(4.0% +3) Frequency (From Clamp) 0- 10KHz +-(1.5% +5) +-(1.5% +5) Logic Frequency 0-60MHz +-(0.5% +3) 0-66MHz +-(0.5% +3) Duty Cycle 10%- 90% +-3.0% +-3.0% Feature Display counts 6000 6600 Jaw Opening 40mm/1.6 40mm/1.6 Auto Ranging Yes Yes Manual Ranging Yes Yes Auto Power Off Yes Yes REL Relative measurement Yes Yes Diode 2.7V Yes Yes Continuity Buzzer <50ohm Yes Yes MAX/MIN Yes Yes Data Hold Yes Yes Display Backlight Yes Yes Low Battery Display Yes Yes Flash Light Yes Yes True RMS True root mean square measurement Yes Yes NCV Non-contact voltage detector Yes Yes Inrush Inrush current measurement Yes Yes USB interface Windows OS Yes General Power Supply 1x9V 6F22 Battery Yes Yes Product Size mm 238x92x50 238x92x50 inch 9.3x3.6x2.0 9.3x3.6x2.0 Product Weight 400g 400g 0.9lb 0.9lb Category CAT.III1000V CAT.IV600V CE CE Note: we'll ship this item via ePacke to USA, usually the delivery time is about 2-3 weeks; For other countries, we will ship it via registered air mail of China Post, usually the delivery time is about 30-40 days. If you want express mail service, pls contact us for extra postage in advance.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	MS2115A
Country of Manufacture	China
MPN	MS2115A
