Dds Spectrum Analyzer Analyser 0.15mhz-1ghz Tracking Generator 110v/220v At6011

US $1,280.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

AT6011 Spectrum Analyzer is a low cost, high performance digital synthesized RF measurement instrument with Tracking Generator and frequency upto 1GHz. It uses VCO phase locked technique. It is rugged and easy to control operating panel. It’s the most stable Spectrum Analyzer you can find with good noise floor performance. Features: Compact and Easy to be carry Frequency range : 0.15~1050MHZ 16bit half numerical display (center frequency, 0.01MHZ resolvability) -100~+13dbm amplitude range, 20KHz, 400KHz Intermediate frequency and 4khz video filter. Phase Locked loop technique Excellent Noise floor performance Tracking signal generator. Specifications: Frequency range: 0.15 to 1050MHz CF adjust range: 0~1050MHz Resolution of frequency display: 10kHz RBW: 400kHz and 20kHz Video filter bandwidth: 4kHz Average noise level: - 90dBm (20kHz Bandwidth) Amplitude range -100dBm to +10dBm Sweep rate 40Hz Reference level -30dBm to +10dBm Frequency generator TCXO DDS Input attenuator accuracy ±1dB/10dB Signal input connector N type Stability ±5ppm/year Aging ±1ppm/year Accuracy ±10kHz Display CRT 8x10 Div Third order intermod -90dBc (two signals > 3MHz apart) Scan width 100kHz/div~100MHz/div, 1-2-5 steps and 0 step Log scale fidelity ±2dB (CF: 500MHz 10dBm attn zero scan RBW 400kHz ) 500MHz AT6011 Tracking Generator Specifications Output: N connector Output Impedance: 50ou Frequency range: 0.15MHz~1050MHz Output level range:-50dBm~+0dBm (in 10dB steps and var) Frequency response: ±2dB Output attenuator: 0~40dBm (4*10dB) Accessories: Power cord, 1pcs of BNC-BNC cable, test leads, antenna, English manual. Tracking generator: Tracking generator is a special signal generator. when unite with the spectrum analyzer, tracking generator have produce a signal, then its frequency is also t he spectrum’s signal .It can precision produce a signal because it used the same VCO oscillator. And it can precision track the signal in the whole sweep frequency model. As this, the full sweep range the generator output a full frequency span as the spectrum span. When the zero span output a simply carrier wave. Tracking signal generator is occurred by mixing the spectrum analyzer’s first mixer and generator’s internal fix frequency phase-lock oscillator. Spectrum analyzer/ tracking generator system have two configuration’s applications: opening circuit and close circuit. In The opening applications, unknown signal input the spectrum analyzer and the tracking generator’s output connect the counter. This configuration is in order to select the precision And high sensitivity to test the frequency, At the time spectrum analyzer will tune to the need test frequency and set to the zero span state. Security: The instrument is accredited for IEC published 10101,"to the electronic equipment security request for test, control and experiment use". And the instrument is according to the I species security regulate series /power supply socket is only can insert to the protection contact point of the external power supply pin. If uses the unprotected connect line, and then must add the grounding protect measure, before do the testing connection must make good insert to the external power supply pin. Grounding metal can touch the part of machine\the socket\connect pin and the power supply’s electrify point (between the live wire\midline) pass the 220VDC insulate electric run experiment .lots of cathode radiation will radiate the X-ray. But, the instrument’s radiation radiance is far below the maximum 36pA/Kg (0.5Mr/h) Note: we'll ship this item via express mail service to USA, Canada, Australia, New Zealand, Ireland, Austria, Belgium, Denmark, Germany, France, Finland, Luxemburg, Malta, Norway, Sweden, Swiss, Italy, Spain, UK, Japan, Korea, Thailand, Indonesia, Malaysia, Philippine, Singapore. Clients from other countries pls contact with us in advance to confirm the different shipping charges before you bid.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	AT6011
Analyzer Type	Spectrum Analyzers
MPN	AT6011
Unit Type	Complete Systems & Mainframes
Country of Manufacture	China
Country/Region of Manufacture	China
Manufacturer	Atten
