Cyclone4 Cyclone Iv Ep4ce30f23 Ver2.0 Nios2 Fpga Development Board

US $125.99

  • Shenzhen, China
  • Jun 9th
????? Cyclone4 Cyclone IV EP4CE30F23 VER2.0 NIOS2 FPGA Development board Description: 1. EP4CE30F23C8N The chip optimized 60-nm low-power process, Cyclone IVE FPGA extends the previous generation Cyclone III FPGA's low power consumption. The latest generation of devices reduce the core voltage, compared with the previous generation product, the total power consumption is reduced by 25%. 2. The core plate board adopts a six PCB design, using high-capacity-pin BGA package more, F484 package, so that the performance and stability of the entire core board has much to offer, and at the same time to provide users with a large number of effective I / O. 3. As the FPGA and memory direct high-speed data exchange. Therefore, a key reason many confounding factors, so it is difficult to increase the speed of many of the development board. So we try to close in the design of FPGA chip. This will minimize disturbances caused because the layout. Our development board SDRAM and FLASH uses a separate bus. This provides a flexible design approach more respect for beginners. 4. The power supply we use the LDO chip and high-capacity filter capacitor design. Because the board running at full speed low power consumption. Therefore, an LDO super stability and low ripple. Stability and low ripple switching power supply interference is no way to compare, you can do high-performance measurement instruments applications System Resource: 1. FPGA chip: EP4CE30F23C7N (FBGA484 package), Speed Grade 7, Logic Elements 28848, Memory Bits 608256, Embedded Multipliers 132, Global Clocks 20, I / O 533, PLLs 4 2. PCB layout: 6 layer high-speed PCB layout, a senior engineer manual routing, and EMC simulation analysis, to ensure the system is running at a high speed above 100M frequency 3. Serial FLASH: Standard EPCS64 (64Mbit), optional EPCS128 (128Mbit), firmware programming or NIOS programs and user data 4. SRAM: Standard configuration a 256K x 16Bit SRAM (4Mbit), independent address data bus easy to use, matching 512K x 16bit (8Mbit), high speed static SRAM 10ns read and write 5. 1PCS SDRAM: 16M x 16Bit SDRAM, 143MHz maximum read and write speed 256Mb, large capacity 6. Parallel FLASH: AM290LV128 16M byte (128Mbit) large capacity to store user data and NIOS program 7. Clock: 2PCS source clock 50M, 20M user-friendly and the division process 8. LCD: 1PCS Standard LCD1602 LCD interfaces, NIOS IP core direct support. Independent I/0, the user can do I/O 9. Key switch(4PCS): pull potential user key input 10. RS232: Standard RS232 interface, MAX232 chip interface converter 11. Power: 5V, 3.3V / 3A, 1.2V / 800MA, 2.5V / 800MA, independent user-friendly and test leads 12. JTAG port: Live debugging FPGA, NIOS write FLASH, cured user program and firmware 13. AS Port: EPCS Serial FLASH programming programming 14. LED: independent I / O (4PCS) 15. System Master Reset: reset button, pull. Users can also be used as a key input 16. Expansion I / O: (J6) 38+ (J7) 38+ (J10) 26+ (J4) 11+ (J3) 44 = 157 (In a lead independent I / O) Package Included: 1 x EP4CE30 VER2.0 core board 1 x USB to DC power cable 1 x RS232 communication lines 1 x LCD1602 LCD 1 x CD Contact Us: 1. We have always been trying to provide the best service and reliable products for every customer, however, accident may happen sometimes, please contact us to resolve any issue before leaving a negative feedback. 2. Please contact us by "Ask a question". Shipping Policy: 1. We Will ship your orders within 5 business days after the payment received. 2. Item shipped via Singapore Post or HongKong Post , It takes about 7-14 business days (USA,CA,AU,UK).others country 10-20 business days(Brzil,India,RU),Exact delivery time depends on postal process. 3. If you do not receive your item by 30 business days,Please feel free to contact us via ebay mail system , we will try our very best to resolve any problems with you Payment Method: 1.All payments must be prepaid. 2.We only accept payment via Paypal.Please kindly check if you can do the payment via paypal before placing an order. Returns&Warranty: 1. We offer 30 days money back guarantee return policy . 2. Our warranty does not extended to any products that are physically damaged or that are not under normal operating conditions as a result of misuse or improper installation on the buyer/user's part. 3. For all returned products, buyers MUST contact us for the returning address. 4. In all cases, buyers pay shipping fees at their own cost to return products for exchange or refund. We will be responsible for the postage of replacements. Refund will be made upon receipt of the returned item.
