Cy8ckit-009 Kit Dev Psoc Proc Module - Cypress Semiconductor

US $15.00

  • Logan, Utah, United States
  • Jan 29th
The CY8CKIT-001 PSoC Development Kit is designed to help hardware, firmware, and software developers in building their own systems around Cypress’s PSoC 1, PSoC 3, and PSoC 5 architectures. The development board gives you the flexibility to configure the power domains. The board can be powered in one of two ways: 12-V 1-A power supply and 9-V alkaline battery.  This full-featured board incorporates three onboard linear regulators that can be used to power peripherals and PSoC modules at voltages between 1.7 V and 5.0 V. These regulators include a fixed 5 V 1-A linear regulator, a fixed 3.3 V 300-mA linear regulator, and a 1.5 V to 5.0 V 300-mA adjustable regulator.  The board also provides the ability to separate the PSoC core VDD rail into two separate rails, analog and digital. In addition, the board is capable of separating the I/O VDD rails, providing flexibility to power the I/O ports at different voltages. The board is equipped with a 2x16 alphanumeric LCD module capable of 1.8 V to 5.0 V I/O. Also included are a mini-B full-speed USB interface, a female DB9 serial communications interface, and a 12-pin wireless radio module interface supporting modules such as Artaflex's Falcon series of CyFi™ Low Power RF wireless modules. The board has a prototyping area containing a small breadboard, complete with I/O port sockets nearby, multipurpose LEDs, mechanical push-buttons, and a multipurpose variable resistor. In addition, three capacitive sensing elements (two buttons and a five-segment slider) are included on the board, allowing evaluation of CapSense® touchsensing applications.
Condition:
New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...
Brand Cypress
MPN CYCKIT-009
