Current Transformer Test Set

US $5,875.00

Pahrump, Nevada, United States
Jan 29th

Open on mobile:
QR code

The CTMP 2012 is a light weight, portable, instrument transformer test set. This instrument offers 0.1% ratio accuracy over the entire range of measurements and provides an unmatched array of test functions. This instrument performs: Ratio and Polarity of current, potential and power transformers. The CTMP will perform a precise ratio test of any transformer and offers 0.1% accuracy over the entire measurement range, it gives you the precision at all ratios that others can't. The CTMP saves ratio data to a flash drive for easy creation of a data sheet. The CTMP 2012 performs a saturation or excitation test of current transformers. It offers two excitation voltage ranges, 0 - 200VAC and 0 - 1000VAC. In saturation test mode the unit displays exciting current and voltage. A real time graph is plotted on the screen during performance of the test allowing observance of the knee. A distortion measurement identifies the spike in the exciting current waveform as the core saturates and flags this point by displaying the word SAT ! above the current reading. The CTMP saves excitation test data to a flash drive for easy creation of a data sheet. Movies and more info on web site www.cttestset.com. The CTMP 2012 includes a phase angle meter. Metering measures AC Voltage, Current and Phase Angle for easy performance of load tests. You don't have to buy another instrument. Clamp on and hard wire inputs are provided. The meter will also ratio a live CT using the clamp on and hard wire imputs. The CTMP 2012 performs a secondary injection test of CT secondary circuits. This mode meters the current output at the X1-X2 terminals and the current input at the I terminals or clamp on. The unit also measures the angle between these currents. This allows injection of a current at the CT secondary terminals and verification that the current direction and amplitude is correct in the connected meters and relays. Ships UPS ground free within the continental US (lower 48). Others must provide shipping account number or arrange transport. More info at www.cttestset.com

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Calvada Technologies
Country/Region of Manufacture	United States
Model	CTMP 2012
Country of Manufacture	United States
MPN	CTMP 2012
