Crl Components 5930-00-968-7543 Rotary Switch - New

US $85.00

Riceville, Tennessee, United States
Feb 16th

Open on mobile:
QR code

CRL Components 5930-00-968-7543 Rotary Switch - New New CRL Components NSN: 5930-00-968-7543 Rotary Switch P/N: PA166-032 Characteristic Details Contact load current rating - 250.0 milliamperes resistive load ac at sea level Contact load current rating - 1.0 amperes resistive load dc at sea level Contact switching action - Breaks before makes 1st section front Contact switching action - Breaks before makes each section rear Contact voltage rating in volts - 115.0 ac at sea level Contact voltage rating in volts - 28.0 dc at sea level Detent rotational torque range - +12.000/+64.000 inch-ounces single actuator First flat length - 0.312 inches nominal single actuator Flat height - 0.100 inches nominal single actuator Individual section quantity - 2 Nonturn device radius - 0.375 inches nominal at 3:00 o'clock Nonturn device type - Key at 3:00 o'clock Operating temp range - -45.0/+145.0 deg fahrenheit Overall diameter - 1.141 inches maximum Overall length - 1.688 inches nominal Mounting method - Threaded bushing single mounting facility Nominal thread size - 0.250 inches single mounting facility Pole quantity - 2 1st section front Pole quantity - 2 each section rear Precious material and location - Contacts silver and terminals silver Precious material - Silver Shaft flat/slot angular location - 30.0 degrees from nonturn device single actuator Shaft diameter - 0.125 inches nominal single actuator Shaft length - 0.375 inches nominal single actuator Shaft type - Round, flatted single actuator Style designator - Circular wafer, bushing mount Switch actuator indexing position quantity - 5 single actuator Switch actuator positioning increment - 30.0 degrees single actuator Switch contact basic design - Nonpile-up symmetrical Terminal type - Tab, solder lug Thread class - 2a single mounting facility Thread length - 0.250 inches nominal single mounting facility Thread series designator - Unef single mounting facility Throw quantity - 5 1st section front Throw quantity - 5 each section rear Please take a look at all of the provided photos before placing your bid to thoroughly inspect the lot contents and condition. Item Condition: New - Old Stock Return Policy: We are offering the buyer a TWO WEEK (14 day) right of return for testing and inspection. Buyer will be responsible for the cost of return shipping. Listed for JP by KK - Located at: TN38E2,116 Shipping weight is 1lbs, 0oz, shipped from our warehouse in Tennessee. (zip 37370) Default Shipping Service: USPS Parcel Select Tennessee residents will be charged 9.00% sales tax. California residents will be charged 9.00% sales tax. (We have offices in both Tennessee and California and are required to charge tax to any shipment sent anywhere in either state.) B#:
