Contec Med Multi Parameter Simulator (ms400 Multiparameter Simulator)

US $399.00

Elk Grove Village, Illinois, United States
Aug 27th

Open on mobile:
QR code

CONTEC MS400 Simulator Multi-parameter ECG Resp Temp IBP Simulation monitor ***Add your product description here*** Introduction MS400 Multiparameter Simulator is a portable device, features in small volume and light weight. It can simulate accurately 12-lead ECG, Respiration, Temperature, 2-channel IBP or 4-channel IBP. And it can be tested in where the monitor is used. Features Simulate 35 kinds of arrhythmia (including Atrial, Ventricular, Premature Beat and Conduction Defects) and pacemaker waveforms (including Asynchronous, Demand Occ Sinus, Demand Freq Sinus, A/V Sequential, Non Capture, Non Function). Simulate four-channel IBP data. Simulate respiration signal with adjustable respiration rate, impedance and baseline impedance, and three kinds of apnea data. Simulate four kinds of temperature data. Simulate square wave, triangle wave, pulse wave and sine wave with adjustable frequency. Simulate standard ECG calibration, adult and pediatric ECG signal. ECG waveform complied with the standard of ANSI/AAMI EC13-2002, AHA, MIT ECG database, other ECG database and user-defined waveform data stored in TF card can be displayed by the simulator and exported to the equipments to be tested. Each waveform can be displayed by sliding the 3.5'' TFT touch screen, easy to operate. Power supply: rechargeable lithium battery or linear adapter, which reduces interference. Optional operation modes: keys and touch screen. Parameters: ECG Conventional: All leads have the same voltage with the II-lead as the reference Amplitude: 0.5,1.0,1.5 and 2.0mV ECG Rate: 15,20,25,30,40,60,80,100,120,140,160,180,200,220,240,260,280,300,320,340 and 350 BPM ECG artifacts: 50 and 60 Hz, muscle, baseline and breathing The elevation of the ST segment: +0.8 to -0.8 mV, the step is 0.1 mV Arrhythmia Atrial: Atrial Fib(coarse), Atrial fib(fine), Atrial Flutter, Sinus Arrhythmia, Missed Beat, Atrial Tachycardia, Nodal Rhythm, Supraventricular Tachycardia Ventricular: Vent Fib (coarse), Vent Fib (fine), PVCs 6/min, PVCs 12/min, PVCs 24/min, Frequent Multifocal, Bigeminy, Trigeminy, Paired PVCs, Run 5 PVCs, Run 11 PVCs, Vent Tachycardia, Asystole Premature Beat: Atrial PAC, Nodal PNC, PVC1 LV Focus, PVC1 E LV Focus, R on T LV Focus, PVC2 RV Focus, PVC2 E RV Focus, R on T RV Focus, Multifocal PVC Conduction Defects: First Degree Heart Block, Second Degree Heart Block, Third Degree Heart Block, Right Bundle Branch Block, Left Bundle Branch Block Four IBP Channels The default: 00/00mmHg Dynamic IBP(unit: mmHg) Channel 1: Artery: 120/80 Radial: 120/80 Left Ventricle: 120/00 Right Ventricle: 25/00 Channel 2: Artery: 120/80 Radial: 120/80 Left Ventricle: 120/00 Right Atrium(CVP): 15/10 Right Ventricle: 25/00 Pulmonary Artery: 25/10 Pulmonary Wedge: 10/2 Left Atrium: 14/4 Channel 3: Artery: 120/80 Radial: 120/80 Left Ventricle: 120/00 Right Atrium(CVP): 15/10 Right Ventricle: 25/00 Pulmonary Artery: 25/10 Pulmonary Wedge: 10/2 Left Atrium: 14/4 Channel 4: Auto Swan-Ganz (every 15 seconds): RA(CVP), RV, PA, PAW (Pulmonary Wedge) Man Swan-Ganz: press ENTER key to change every time Static-Pressure Levels Channel 1: 0, 80, 160, 240, 320 and 400mmHg Channel 2: 0, 50, 100, 150, 200 and 250mmHg Channel 3: 0, 20, 40, 60, 80 and 100mmHg Channel 4: P4 tracks the static pressure levels of P3 Respiration Respiration Rate: 0 (Apnea), 15, 20, 30, 40, 60, 80, 100, 120 and 150 R/MIN Impedance: 0.2, 0.5, 1.0 and 3.0 Baseline impedance: 500, 1000, 1500, 2000 Apnea: 12 s, 22 s, 32 s Temperature Four temperature: 0(32°F), 24( 75°F), 37(98.6°F), 40(104°F) Accessories Standard accessories 9V/1A(CE) power adapter, an User manual, a packaging box, a plastic packaging. Optional accessories a power adapter(15V/1A)(UL), a power adapter(15V/1A), a temperature cable, an IBP cable, a CD disk(including a case conversion software) Physical characteristic

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	MS400
MPN	69450435
Modified Item	No
Brand	CONTEC
Country/Region of Manufacture	China
Intended Use/Discipline	Simulate 35 kinds of arrhythmia, Simulate four-channel IBP data., Simulate respiration signal, Simulate four kinds of temperature data., 3.5'' TFT touch screen, Biological Laboratory, Emergency Medicine, Simulate square wave, triangle wave, pulse wave, Each waveform can be displayed
Custom Bundle	No
UPC	658126802161
