Connector, Plug, Electrical P/n Ms3406d16-10p Qty 2 J1022r

US $242

Danville, Virginia, United States
Jan 29th

Open on mobile:
QR code

AAJD Thread Class 2A and 2B AAJF Thread Direction Right-hand and right-hand AAQL Body Style Straight shape, internal coupling ABHP Overall Length 2.125 inches maximum ADAV Overall Diameter 1.250 inches maximum ADZC Environmental Protection Moisture resistant and vibration resistant and salt water resistant AFQR Threaded Device Type Back shell and coupling facility AFQW Mating END Quantity 1 AFQX Contact Position Arrangement Style 16-10 single mating end AFQZ Contact Removability Removable single mating end single contact grouping AFRC Contact Maximum Current Rating IN Amps 41.0 single mating end single contact grouping AFRD Contact Maximum AC Voltage Rating IN Volts 500.0 single mating end single contact grouping AFRE Contact Maximum DC Voltage Rating IN Volts 700.0 single mating end single contact grouping AFRN Polarization Method Key, multiple key groove AFRP Insert Position IN DEG 0.0 AFRT Shell Type Solid AFRV Connector Locking Method Internally threaded coupling ring AKMG Nominal Thread Length 0.290 inches and 0.602 inches CQJX Nominal Thread Size 1.000 inches and 1.000 inches CQTM Terminal Location Back single mating end single contact grouping CQZG Insert Material Plastic silicone mineral filled single mating end CSCF Terminal Type Crimp single mating end single contact grouping CSPT Shell Material Aluminum alloy CSWM Shell Surface Treatment Cadmium CTBC Shell Surface Treatment Document AND Classification QQ-P-416, ty 2, cl 3 fed spec single treatment response CXCG Included Contact Quantity 3 single mating end single contact grouping CXCL Included Contact Type Round pin single mating end single contact grouping TEST Test Data Document 81349-MIL-C-5015 specification (includes engineering type bulletins, brochures, etc., that reflect specification type data in specification format; excludes commercial catalogs, industry directories, and similar trade publications, reflecting general type data on certain environmental and performance requirements and test conditions that are shown as "typical", "average", "nominal", etc.). THSD Thread Series Designator Unef and unef ZZZK Specification/Standard Data 81349-MIL-C-5015 government specification 23 N Ohio Class Ssbn (Trident) 34 F Ballistic Missile Early Warning Sys. (Bmews) CN N Fleet Vertical Package Conveyors EX N Los Angeles Class Ssn (688) EZ N Ticonderoga Class Cg (47) FP N Ship, Supply Class Taoe HD A Heater, Duct-Type, Multi-Fuel, 120, 000 Btu/Hr, Skid Mounted HZ N Forrestal Class Cv JA N Nimitz Class Cvn JD N Arleigh Burke Class Ddg JF N Oliver Perry Class (FFG-7) JG N Seawolf Class Ssn JK N Wasp Class Lhd JL N Tarawa Class Lha JX N Avenger Class Mcm KV N Fleet Modernization Program - Cruisers/ Destroyers MQ N Blue Ridge Class LCC-19 TK N Fms - MHC-51 Class Machinery and Ship Control System W5 N Austin Class (LPD-4) XC N Nuclear Reactor Boundry Area YJ N Virginia Class Submarine, SSN-774 YR N Fms - Build Frigates Class Ships ZP A Pdise/Dise M40 Power Distribution Illum Sys, Electronic ZQ A Pdise/Dise M60 Power Distribution Illum Sys, Electronic ZT A Dise Utility M46 (Distribution Illumination System Electronic)

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	MS3406D-16-10P TRU-FAB Inc.
Country/Region of Manufacture	United States
MPN	MS3406D-16-10P TRU-FAB Inc.
NSN	5935-01-025-2137
