Cnc Router Plans ,3 Axis Working Area 65x45x15cm , 65x65x15cm , 65x85x15cm (xyz)

US $8100

Bangkok, Thailand
Jun 8th

Open on mobile:
QR code

*** This is not a Kit, Plans Only *** iD2CNC-SS v.1.0 After clear payment i will email you the plans to your Paypal email address. (No Refund , Digital Informations). You will receive the detail plans which include list below. Files will send via email in 24-48 hours after receive payment. Note :: Files will send to your Paypal email. Plans Contents :: – B.O.M with estimate cost (estimate cost build about $1300-1500).. – Machine explode views & part detail document. – Reference parts detail document. – Electronic wiring diagram. – Mach3 config guide. – Aluminum 2D (DXF Files). - Google Sketchup 2D file with measurement scale. Estimate cost build :: – Machine build by using wood router , estimate cost about $1,300-1,500. If you need to use 1.5kw water cooled spindle + inverter then cost will add 250-350$ *** This plan include all 3 different size of machine as detail below *** iD2CNC-SS Machine v.1.0 Specification (65cm x 45cm x 15cm , XYZ) :: – Machine working area 650mm x 450mm x 150mm. – Machine size 1,050mm x 800mm x 750mm (width (X) x length (Y) x height (Z)). - Linear rod rail size 16mm (RM1605/RM1610) for all axis. - Ball screw 16mm (RM1605/1610) for all axis. - Use standard ball screw support BK/BF12 , FK/FF12. - Aluminum frame use aluminum alloy 5083 10mm & 12mm. – Design using metric unit (mm). iD2CNC-SS Machine v.1.0 Specification (65cm x 65cm x 15cm , XYZ) :: – Machine working area 650mm x 650mm x 150mm. – Machine size 1,050mm x 1,000mm x 750mm (width (X) x length (Y) x height (Z)). - Linear rod rail size 16mm (RM1605/RM1610) for all axis. - Ball screw 16mm (RM1605/1610) for all axis. - Use standard ball screw support BK/BF12 , FK/FF12. - Aluminum frame use aluminum alloy 5083 10mm & 12mm. – Design using metric unit (mm). iD2CNC-SS Machine v.1.0 Specification (65cm x 85cm x 15cm , XYZ) :: – Machine working area 850mm x 650mm x 150mm. – Machine size 1,050mm x 1,200mm x 750mm (width (X) x length (Y) x height (Z)). - Linear rod rail size 16mm (RM1605/RM1610) for all axis. - Ball screw 16mm (RM1605/1610) for all axis. - Use standard ball screw support BK/BF12 , FK/FF12. - Aluminum frame use aluminum alloy 5083 10mm & 12mm. – Design using metric unit (mm). Term of use :: - You can not use this plan to build the machine for sale or use it as commercial use. - You can not redistribute this plans , use for personal only. - You can not re-sale this plans, use for personal only. - You use this plans is at your own risk. - No support includes. Sample Build Log :: iD2cnc.com iD2CNC-SS v.1.0 build log Files will send via email in 24-48 hours after receive payment. Note :: Files will send to your Paypal email.
