Cnc Router Machine 26'' X 41'' X 8'' Steel Welded

US $2700

Hamtramck, Michigan, United States
Nov 5th

Open on mobile:
QR code

Cnc Router Machine 26 x 41 x 8 Made of Steel We decided to build Cnc machines that are made from steel and are fully welded. Y axis frame is form steel square pipe 2 '' x 2 '' wall 1/8 X axis bridge is build from 3 '' x 3 '' x wall 1/4 Z axis is made form 3/4 '' aluminium Plate supported by steel plate It's a very strong machine. Wiring tutorial : wire and setup digital driver with C10 board, and power supply USA Phone (248) 778-5715 Canada Phone (519) 996-2519 4 x High-precision TBI ball screw Q16mm pitch 5mm (C7) 2 x 25mm Precision Linear Rail Guide-way with 4 V bearing blocks for Z 4 x Linear SBR 20mm for Y and X axis 1 x Set of nuts, bolts and washers Aluminum parts Z axis Plate Thickness 3/4 '' Steel Parts Y axis Frame 2 '' x 2 '' x 1/8 '' X axis bridge 3 '' x 3 '' x 1/4 '' Side steel Plate 3/4 '' SPINDLE 1.5KW Water-cooled Spindle motor + VFD Diameter :80mm x Length: 205mm Power: 1.5 KW Voltage: 220V CNC Driver Controller 4 x Digital Stepper driver:: 24V to 50V CCK5560 1 x Power supply: 600W 48V 12A 1 x C10 Breakout Board 6 axis Aluminium Box 20'' x 20'' x 4'' extra cost of $155 Stepper Motor 4 x Stepper Motor 425 oz In. 1.8° /200 Steps Per Rev. 3 Amps Current Per Phase 4-wire Bi-polar Work area dimensions Z-axis travel 8" X-axis travel 26" Y-axis travel 41" Speed 40000 mm/minute The weight of Cnc router 490 pound NOTE: You can always add/upgrade components just contact us describing what you wish to add and we will do our best to satisfy. Machine will be shipped in 3 weeks option available Spindle 1.5kw + VFD 110V extra cost $160 Spindle 2.2kw 220V extra cost $185 Water pump for spindle Software Software Demo Rhino 4.0 Rhino cam 2.0 for g- code Mach3
