Cnc Plasma Float Head - 6" Z Axis. Linear Z - K2 Cnc Specs - Velox Cnc - Za650p

US $385.00

  • Orange, California, United States
  • Jan 30th
ALL NEW parts - VELOX CNC 6" Z axis for Plasma with Rigid 4 Bearing Configuration. Nema 23, or Nema 34 (Addition Charge). Plasma mount sold separately, $72.95. The red switch is used for router applications and is not included. This proven product will make your DIY experience more enjoyable and will compliment your one of a kind machine! When cutting anything, a rigid machine will produce a better finish! Don't make your own Z axis that may bind, be too loose, and may require too much machining. Buy this Z axis from VELOX CNC and get cutting faster. This product is under-priced to sell. We hope that once you obtain a VELOX CNC Product you will understand how much VELOX CNC prides itself in being the best providers of CNC machines, components and service for the money! We hope that we can earn your business. Video above is of the Z axis for routers. Please use this as a reference. Feel free to email me if you have any questions. This item has a Lead Time of 15 to 25 Days. 4 qty 20mm shafts and bearing. Top and bottom leadscrew support. Leadscrew pitch is .1, 10 revolutions = 1.0", one start lead. Resolution of leadscrew is .0005" or better. leadscrews and anti-backlash nut style motion. Included is a Nema 23 mount with 10-32 screws. Nema 34 is available for an additional $15.00. .200" pitch with 2 start will move 1.00" with 5 rev. is available for an additional $35.00. One (Home switch/top material zero switch) included and installed. Leadscrew coupler with a 0.25" hole diameter. 0.250" Free 0.375" or 0.500" ID coupler is available for an additional $10.00. Plasma mount sold separately, $72.95. The red switch is used for router applications and is not included. Direct drive coupler with anti-backlash. 20mm shafts on all axis. Recirculating steel bearings on all axis. Direct drive coupler with anti-backlash. Precision VELOX Exclusive aluminum extrusions providing smooth motion. 6061 aircraft grade aluminum. Home switches. + Used for homing material on plasma. + Not used for limiting. Leadscrews and anti-backlash nuts. + 0.1 pitch lead screws. + 120 IPM Max Traverse default setting on Mach from VELOX. + 80 to 120 IPM Max recommended Feed Rate. + Backlash: 0.0005 inch + Resolution: 0.00045 inch INCHES METRIC DECIMAL mm .00025" .00635mm .00050" .0127mm .001" .0254mm .003" .0762mm .006" .1524mm   Available router mounts if you want to convert this to a router style z axis. Trimmer router mounts Bosch Colt mounts + 35K max RPM, great for 1/8 bits. + Precision .0005" collect sold by VELOX CNC. Porter Cable 7310 mounts Kress mounts + 43.18mm (international type) + 1.7" 2-3 HP Router mounts Porter Cable 892 and 690 + 3.5" diameter, 11" circumference. + VELOX recommends for 1/4 and 1/2 bits. Porter Cable 7518 + 4.27" diameter. Bosch 1617EVS + 3.5" Hitachi M12VC + 3.27" Mikita RD1101 + 3.20" - 3.22" Diameter. Dewalt DW616 + 3.5" USPS Priority Shipping and Lead time: Shipping and lead time is 5-20 days. We build to order and the lead time is dependent on the inventory. Please contact us to request faster ship times. The item will ship USPS or UPS. USP Shipping: We can ship ground only if requested. We reserve the right to charge handling fees if needed if you request UPS shipping. We can combine shipping if you decide to buy a router mount or any other VELOX CNC products from the same eBay account. Warranty: Sold with 14 day warrant (un-used). You must email us for a return authorization prior to shipping. CAD: We will provide limited drawings after you purchase. We will NOT provide the CAD files in IGS, Solidworks, or and other 3D format files.
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Grade Professional
Item 1 Item 1
K2 CNC Plasma Head
