Charter Engineering B5f-330100/p Spdt Coaxial Relay Switch 24 Vdc Dc-12.4 Ghz

US $830

Phoenix, Arizona, United States
Nov 15th

Open on mobile:
QR code

Charter Engineering B5F-330100/P SPDT Coaxial Relay Switch Comes with what you see in the pictures. If you don't see it, you probably won't get it. Specifications are from Charter Engineering and may vary slightly due to upgrades, options, or revisions this unit may or may not have. These units are pulls and are guaranteed to work. They come with 3 cables that are 1 foot~ long. The Unit's Serial Number Tag Reads: Model Number: B5F-330100/P Serial Number: Multiple Available Voltage: 24.0 VDC Link to the Datasheet: Charter Engineering B5F Series Coaxial Relay Datasheet Breakdown by Part Number: Switch Series: B5 - SPDT Type N Actuator: Failsafe Frequency Bandwidth: DC - 12.4 GHz Voltage: 20 - 30 VDC (24.0 V nominal) Common Polarity: Not required Power Interface: Solder Terminal (Top of Switch) Options: No other options required Intermodulation: Standard Switch Special Options: High Temp, High Power Connector Specifications: Frequency Range: DC - 12.4 GHz VSWR (Max.): 1.50:1 Insertion Loss (Max.): 0.50 Isolation (Min.): 60 Impedance: 50 Ohms Mechanical: Contact: Break before make Actuator: Failsafe Switching Speed: 20 mSEC Max. Electrical: Actuator Voltage: 24.0 VDC Actuator Current: Contact CEI Power Handling: 750 WCW @ 1.0 GHz (Opt. /P) Environmental: Operating Temperature: -40°C to 90°C Sine Vibration: 30 G'S ms Random Vibratoin: 20 G'S ms Life: 1,000,000 cycles Finish: RF Cavity: Aluminum Electroless Nickel Plated per MIL-C-26074, Class 4 Enclosure: Aluminum, Black Contact: Beryllium Copper, Gold Plated per MIL-G-45204 Connector Shell: Cres, Passivated Per QQ-P-35 or Brass, Electroless Nickel Plated per MIL-C-26074 For More Pictures Please Click the Following: Picture 2 - Front View Picture 3 - Back View Picture 4 - Top View Picture 5 - Bottom View Picture 6 - Serial Number Tag For Domestic Customers: Packaging, handling, and order processing included in shipping in all domestic shipments as quoted by the shipping calculator. For International Customers there is a $0.00 minimum for packaging, handling, and order processing. International shipping to be determined by destination. Prior to shipment I need to know the following information: (1) Are you the end-user of this item? (2) If you are not the ultimate end-user of the item, please state the ultimate end user's name. (3) What is the ultimate country destination? If you have any questions please call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 11/15/16
