Bullard Sales Literature Catalog Nc Vertical Lath

US $210

Holland, Netherlands
Oct 30th

Open on mobile:
QR code

14 Pages Bullard Sales Literature Catalog Cat. No. DAT 36-124 (6-79) NC Vertical Lathes 36in.(914mm) to 124in. (3150mm) All my Bullard items come of a distrubutor out of Rotterdam (The Netherlands) are full original or copy manuals from the manufacturer/distrubutor are unused, clean and no notes or underlining. Item wil be sent in an cardboard box. All books are complete and in good condition, unless otherwise stated. Minor defects (few annotations and underlinings, stamps, etc.) have not been mentioned in all cases. NC Vertical Lathes Bullard's new, all electric servo Dyn-Au-Tape IV vertical lathes are available in two basic configura- tions — the VTL with turret, ram and side heads and the all-new Tool Block Changer. These are the "Bullard Verticals," designed and built tor endurance, precision and maximum productiv- ity. They are NC or CNC. Table sizes range from 36 in. (910mm) to 124 in. (3150mm) in diameter. Dyn-Au-Tape IV VTLs, with a tive-sided turret hold ten tools. Op- tions include a ram head with either a tour or eight position indexing turret and a side head with four po- sitions and combinations of these heads. Bullard VTLs have been the Standard in the industry since 1880. In 1974, the ultimate in vertical lathes was introduced —the Dyn- Au-Tape IV Tool Block Changer. The basic machine is the same. lts operating concept is unique, The library of tools and the system to supply tools to the ram are inde- pendent. It's a vertical lathe that "stays in the cut." All tooi hand- ling, adjustment, even set-up for the next program are accomplished during "up-time." Tool blocks change in seconds. Production hours are cut to minutes. The Bullard Tool Block Changer and Bullard VTLs—for those whose goal is PRODUCTIVITY. Contents Construction Bed ...................................... 4 Cross Rail ............................ 4 Table Carrier Bearings........ 5 Headstocks .......................... 5 Heads .................................. 6 Features Turret Index Registry and Locking...................... 8 Pendant Control.................... 8 Lubrication .......................... 9 Coolant ................................ 9 Safety Features.................... 9 Chucks and Tables.............. 9 Ways .................................... 9 Options ................................ 9 Servo Drives ........................ 10 Ball Screws .......................... 10 NC ........................................ 10 Stored Parts Programs........ 10 Chip Handling ...................... 11 Tool Block Changer................ 12 Ram ...................................... 13 Head .................................... 13 Carousel .............................. 13 Tool Blocks.......................... 13 Transporter .......................... 13 Tool Changer ...................... 13 Tooiing ................................ 13 Table Speeds and Machine Weights ................ 14 The actual shipping cost (to be determined based on your country) Cheapest shipping method is at buyer's risk via standard mail or economy airmail (other destinations). Shipments can be registered, if buyer prefers. Costs depend of weight, priority and destination. I will inform you
